6 720 808 869 (2014/06)Compress 3000 DW FOO
Appliance details | 9
3.3 Specification tables
Model HP 270-2E 0 FOOV/S
Running ambient air temp. °C -7 °C/+40 °C
Outlet Water Temp. °C setpoint  1°C
Minimum Inlet Water Temp. °C 3 °C
Maximum Inlet Water Temp. °C 70 °C
Power supply Ph-V-Hz 1ph / 230V-240V / 50 Hz
IP rating IP X4
Storage size l 270
Water heating (HP cycle)
1)
Heating capacity kW 1.5
Max. input
kW 0.6
Max. current
A2.6
Water heating (Full mode)
1)
Heating capacity kW 3.15
Max. input
kW 2.25
Max. current
A9.8
COP
2)
3.3
Unit Dimension (D×H) mm 705 x 1840
Packing (W×H×D)
mm 730 x 2004 x 730
Net/gross weight
kg 113/128
Sound pressure level at 2 m dB (A) 43
Refrigerant type/Mass kg R134a / 0.375
Max. refrigerant circuit pressure kPa 2700
PTR valve setting
3)
kPa 1000
Throttling type Thermal expansion valve
System protection High pressure limiter, Temperature limiter
Compressor Model WHP01900
Type
Rotary
Brand
Highly
Input
W 700
Fan motor Model W1G230EB
Brand
EBM Papst
Input
W28
Speed
r/min 1500
Water connections Water inlet ¾ BSP inch
Water outlet
¾ BSP inch
Max. water working pressure
kPa 1000
PTR valve joint
½ BSP inch
Max inlet pressure
kPa 800
Heat exchanger
Double wall plate heat exchanger
Electric heating element Rated power input at 230 V kW 1.65
Rated current at 230 V
A7.2
Table 2
1) Air at 15 °C and voltage supply 230V
2) According to EN255-3 by using air at 20 °C, water inlet at 15 °C and factory settings
3) PTR valve power capacity: 10 kW
