Bosch Security Systems
Divar | Installation Manual | Quick install EN | 2-3
Primary connections
1. Connect the cameras to the BNC loop-through camera inputs (automatically
terminated).
2. Connect monitor A to the BNC output MON A.
Optional connections
3. Connect monitor B to the BNC output MON B.
4. Connect up to 16 (alarm) inputs via the supplied 25-pin D-type connector
board.
5. Connect up to 4 alarm output relays via the supplied 25-pin D-type connector
board.
6. Connect a keyboard unit to the KBD IN socket.
7. Connect a pan/tilt/zoom control unit via the supplied 15-pole D-type
connector board
8. Connect to your network via the Ethernet port or use the RS232 connector to
connect directly to a PC serial port.
9. Connect an external storage unit via the narrow 50-pin high density SCSI-2
port. (For Divars with an internal DVD writer: Do not remove the supplied
terminator from the SCSI connector unless you connect a disk array! )
Powering up
10. Switch on all connected equipment.
11. Connect the power cord to the unit.
First-time use
The unit starts with a multiscreen display. The Quick install menu opens the first
time you use the unit. Fill in these basic settings to get the unit operational.
Select the Install item to save your settings and close the menu. When you close
the Quick install menu, the unit begins recording automatically.
To open the Quick install menu at any other time:
1. Press the ALT key to enter the alternate function mode.
> The ALT indicator lights.
2. Press the menu key .
> The main menu appears full-screen on monitor A.
Select the System settings menu and then the Quick install submenu.
Navigating
• Use the arrow keys to move through a menu or list.
• Use the select key to select a submenu or item.
• Use the escape key to go back or to switch off the menu.
