Page 124 P/N: 4998152533-02 Copyright 2007 Bosch Security Systems, Inc. DS7200V2-UK Installer's Guide
PART V: REFRENCE MATERIALS
63.0 Control Panel Events and Reporting Formats
The following table includes each control panel event, the description for each event as it appears in the control panel log, the
reports sent for each event, the zone types linked to the event, and the RPS Event Alert Group number. The RPS Event Group
numbers also correspond with the Personal Dialing Format Event Group numbers. See
Personal Dialing Format Configuration
on page 106 for more information.
The last column, Status Reports, indicates System Status events. An “R” indicates that reports for the event follow the System
Status routing. An “S” indicates that the event follows the System Status Swinger Count. System reports do not include an
Area number; they use the account number for Area 1.
If the control panel is configured for network communication, reports are sent using the Contact ID format.
The event numbers shown in the following table are the same numbers that show up on a pager for each corresponding
report.
Event #
Event as shown
in Panel Log
SIA Report
SIA Report Data
Contact ID Report
Event Description
Zone Types
Linked to Event
RPS Event
Group
Status
Reports
01 AC Fail AC Trouble AT 301 AC Loss AC Power to panel
interrupted.
12 R S
02 AC Restore AC Restoral AR 301 AC Loss AC Power to panel
restored.
12 R S
03 Alarm,Tamper Tamper Alarm ri {area} TA {loop} 137 Tamper Alarm, Tamper Zone
Type.
4-Tamper 3
04* Alarm,Emergency
Emergency
Alarm
ri {area} QA {loop} 101 Personal
Emergency
Alarm, Emergency
Zone Type or ABC
key programmed for
emergency response.
[Q] button.
5- Emergency
Emergency Key
3
05 Alarm,Panic Panic Alarm ri {area} PA {loop} 120 Panic Alarm, Panic-Visible
Zone Type.
6- Visible Panic
Emergency Key
3
06 Alarm,Invisible Holdup Alarm ri {area} HA {loop} 120 Panic Alarm, Panic- Invisible
Zone Type or ABC
key programmed for
panic response.
7-Invisible Panic
Emergency Key
3
07 Alarm,24-hr Burg Burglary Alarm
ri {area} BA {loop} 133 24 Hr Safe Alarm, Burglary Zone
Type.
8- Burglary
15- Door
3
08 Alarm,Cntrl,Dly Burglary Alarm
ri {area} BA {loop} 134 Entry/Exit Alarm, Delay 1 or
Delay 2 Zone Type.
11- Delay 1
12- Delay 2
3
09 Alarm,Cntrl Burglary Alarm
ri {area} BA {loop} 130 Burglary Alarm, Keyswitch or
Follower or Instant
Zone Types.
10- Keyswitch
13- Follower
14- Instant
3
10 Cross,Tamper Burglary Alarm
Cross Zone
ri {area} BM {loop} 137 Tamper Alarm, Tamper Zone
Type with Cross Zone
Option selected.
4-Tamper 3
11 Cross,Emergency
Burglary Alarm
Cross Zone
ri {area} BM {loop} 101 Personal
Emergency
Alarm, Emergency
Zone Type with Cross
Zone Option selected.
5- Emergency 3
12 Cross,Panic Burglary Alarm
Cross Zone
ri {area} BM {loop} 120 Panic Alarm, Panic-Visible
Zone Type with Cross
Zone Option selected.
6- Visible Panic 3
13 Cross,Invisible Burglary Alarm
Cross Zone
ri {area} BM {loop} 120 Panic Alarm, Panic- Invisible
Zone Type with Cross
Zone Option selected.
7-Invisible Panic
3
14 Cross,24hr Burg Burglary Alarm
Cross Zone
ri {area} BM {loop} 133 24 Hr Safe Alarm, Burglary Zone
Type with Cross Zone
Option selected
8- Burglary 3
15 Cross,Cntrl,Dly Burglary Alarm
Cross Zone
ri {area} BM {loop} 134 Entry/Exit Alarm, Delay 1 or
Delay 2 Zone Type
with Cross Zone
Option selected.
11- Delay 1
12- Delay 2
3
16 Cross,Cntrl Burglary Alarm
Cross Zone
ri {area} BM {loop} 130 Burglary Alarm, Follower, or
Instant Zone Types
with Cross Zone
Option selected.
13- Follower
14- Instant
3
Table 47: Control Panel Events and Reporting Formats
* Help Function Keys report as Zones 100, 101, and 102. The [Q] button on a keyfob reports as User Number +200.
