F 002 DG9 918 2017-10-16| Bosch Limited
Technical data | EPS 610 | 33 en
10.3 Tightening torques
For the purpose of safety, the tightening torques listed
in the following sections must be used during routine
maintenance or during repair.
10.3.1 Fastening parts
Tightening torques of the fastening parts:
Size 5.6 6.8 8.8 10.9
M 5 5 +2
M 8 14 +3 23 +3 32 +5
M 10 45 +8 65 +8
M 12 80 +8 125 +10
M 14 90 +10 135 +10
M 16 135 +10 210 +10
10.3.2 Coupling halves
On the injection-pump camshaft
Size Bevel gear
diameter [mm]
Tightening torque
[Nm]
M 12 17 60 +10
M 14 x 1,5 20 80 +10
M 18 x 1,5 25 130 +10
M 20 x 1,5 30 200 +20
M 24 x 1,5 35 250 +50
M 30 x 1,5 40 300 +50
10.4 Machinery noise information
pursuant to the bench safety code
R Noise measurement performed in accordance with
DIN EN ISO 3744 and DIN EN ISO 11201 standards.
R Sound power measurement performed in accor-
dance with DIN ISO 3744 standard.
Measurement
conditions
Test bench without
injection pump
Test bench with
injection pump
(6 cylinder)
Speed min-1 0 4000 1050
Acoustic
power level L
WA
,
db
67 86.43 83.48
Workplace relat-
ed sound pressure
level L
pA
,
db
57.2 83.18 78.4
