Product description | EPS 610 | 7 en
3.5 Description of unit
3.5.1 EPS 610
1
2
3
4
5
6
7
8
9
10
11
12
459877_80Nkv
13
14
Fig. 1: EPS 610
1 Measuring glass carrier (MGT) assembly
2 "Mains on" indicator
3 Emergency stop
4 Human Machine Interface (HMI)
5 MGT illumination switch
6 Motor Right Hand (RH) side panel
7 Control cabinet door
8 Graduated flywheel
9 Coupling guard
10 Fuel injection pump mounting bed
11 Bottom right panel
12 Pressure control valve regulator
13 Swivel arm
14 Swivel plate
