Engineering Submittal Sheet
SM Series
Residential Geothermal Heat Pumps
Physical Data
Description Unit
Value
SM024 SM036 SM048 SM060 SM070
Compressor Type (Qty 1) — Scroll Scroll Scroll Scroll Scroll
Refrigeration Charge VT/HZ Oz. 58/58 98/85 88/77 110/100 114/114
Max Water Working Pressure PSIG/kPa 450/3100 450/3100 450/3100 450/3100 450/3100
Constant Torque High Effi ciency Motor
Fan Motor Type/Speeds —
Const Torque
Motor / 5 speed
Const Torque
Motor / 5 speed
Const Torque
Motor / 5 speed
Const Torque
Motor / 5 speed
Const Torque
Motor / 5 speed
Fan Motor HP 0.33 0.75 0.75 1.00 1.00
Blower Wheel Size
Inch
(Dia. x W)
10 X 8 11 X 9 11 X 9 11 X 11 11 X 11
Variable Speed Constant CFM High Effi ciency Motor
Fan Motor Type/Speeds —
Variable Speed
Const CFM
Variable Speed
Const CFM
Variable Speed
Const CFM
Variable Speed
Const CFM
Variable Speed
Const CFM
Fan Motor HP 0.33 0.75 0.75 1.00 1.00
Blower Wheel Size
Inch
(Dia. x W)
10 X 8 11 X 9 11 X 9 11 X 11 11 X 11
Water Connection Size
FPT Swivel Connection Inch 1.0 1.0 1.0 1.0 1.0
Coaxial Coil Volume Gal 0.33 1.18 0.62 1.07 1.12
Condensate Connection Inch FPT
¾¾¾¾¾
Vertical Cabinet
Air Coil Dimensions (H x W)
Inch
(H x W)
24 X 20 32 X 26 32 X 26 38 X 26 38 x 26
Nominal size of Standard Filter - 2"
MERV11
Inch
(L x H)
24 X 24 (1) 16 X 30 (2) 16 X 30 (2) 20 X 30 (2) 20 X 30 (2)
Weight - Operating lbs 250 360 340 410 440
Weight - Shipping lbs 350 475 450 530 560
Horizontal Cabinet
Air Coil Dimensions
Inch
(H x W)
18 X 31.5 20 X 42 20 X 42 20 X 49 20 X 49
Nominal size of Standard Filter - 2"
MERV11
Inch
(L x H)
18 X 18 (2) 20 X 24 (2) 20 X 24 (2) 18 X 20 (3) 18 X 20 (3)
Weight - Operating (lbs) lbs 260 375 355 430 460
Weight - Shipping (lbs) lbs
360 495 470 550 580
4 of 44
