1 689 989 072 2010-06-09| Robert Bosch GmbH
Technical data | KTS 340 | 17KTS 340 | 17 | 17 en
7. Technical data
7.1 General data
Property Value/Range
Operating voltage 11 VDC — 34 VDC
Power consumption approx. 50 W
LCD 8.4"
800 x 600 pixels
Dimensions (L x W x H)
235 x 290 x 67 mm
9.25 x 11.42 x 2.64 inch
Weight (without connecting cables) 2100 g
4.6 lb
Operating temperature 5 °C – 40 °C
41 °F – 104 °F
Relative humidity 90 % (at 25 °C)
Degree of protection IP 40
7.2 Interface protocols
The following interfaces and their associated protocols
are supported for control unit diagnosis in compliance
with ISO 15031:
R ISO/DIS 15765-4 (CAN) - baud rates: 250 kbit/s and
500 kbit/s)
R ISO 9141-2 Fast
R ISO/DIS 14230-4 (keyword protocol 2000) 5 bauds
R ISO/DIS 14230-4 (keyword protocol 2000) Fast
R ISO/DIS 11519-4 (SAE J1850) PWM
R ISO/DIS 11519-4 (SAE J1850) VPW
7.3 Power supply unit
Property Value/Range
Input voltage 100 VAC — 240 VAC
Input frequency 50 Hz — 60 Hz
Output voltage 15 V
Operating temperature 0 °C — 40 °C
7.4 Multimeter specifications
R CH1 zero potential (blue input may be connected to
live measurement points). Input resistance
> 900 kohms.
R CH2 non-floating (black ground input must be
connected to vehicle ground). Input resistance
> 900 kohms.
7.4.1 DC measurement (CH1 and CH2)
Property Value/Range
Measuring range 200 mV — 60 V
Accuracy of CH1 ±0.75 % of measured value,
plus ±0.25 % of measuring range
Accuracy of CH2 ±2 % of measured value,
plus ±0.5 % of measuring range
Resolution 100 µV — 100 mV
(depending on measuring range)
7.4.2 Measurement of AC and rms value
(CH1 and CH2)
*)
Property Value/Range
AC frequency range 10 Hz — 400 Hz (-3 dB)
Measuring range 200 mV — 60 V
AC accuracy at 100 Hz
rms accuracy at ≤ 100 H
±2 % of measured value, plus
±0.5 % of measuring range
Resolution 100 µV — 100 mV (depending
on measuring range)
*)
The measuring ranges in measurement modes "U" and "I" are
specified as peak-to-peak values. Consequently, the digital
display box is "grayed out" if the set measuring range is briefly
exceeded (overload).
7.4.3 Resistance measurement (CH1)
Property Value/Range
Measuring range 100 — 1 M
Accuracy up to 200 K ±0.75 % of measured value
plus ±0.25 % of measuring ran-
ge
Accuracy up to 1 M ±2 % of measured value
plus ±0.25 % of measuring ran-
ge
Resolution 0.1 — 1000 (depending on
measuring range)
Input resistance > 9 M
