Product description | KTS 340 | 7KTS 340 | 7 | 7 en
3. Product description
3.1 Use
The KTS 340 is a system tester for control unit diag-
nosis, trouble-shooting, repair and service in auto-
motive workshops. The functions of the KTS 340 with
licensed ESI[tronic] are as follows:
R Vehicle identification
R Vehicle information
R Diagnosis
R Service information
R Maintenance
i The KTS 340 is designed for operation in the WLAN
2.4 GHz for USA, Canada and Mexico.
The device satisfies the requirements of the R&TTE
(Radio Equipment and Telecommunications Terminal
Equipment) Directive, as confirmed by the CE mark.
! The KTS 340 is a precision device, which is not to
be subjected to sources of heat (e.g. direct sun-
light), impact, vibration, magnetic fields and exces-
sive soiling. The KTS 340 may only be opened for
changing the battery (the battery referred to in this
manual is a rechargeable battery).
3.2 System requirements
A PC/laptop with WIN XP (SP2), WIN Vista
TM
Home
Premium, WIN Vista
TM
Business or WIN 7 operating
system and at least one free USB port is required for
KTS 340 licensing using the ESI[tronic] Startcenter and
the software update for KTS 340 control unit diagnosis.
The USB port must support the USB 2.0 or USB 1.1
protocol.
3.3 Scope of delivery
Description Order number
KTS 340
Power supply unit
Power supply lead
1 687 022 890
1 684 461 161
USB connecting cable, 3 m 1 684 465 562
OBD diagnostic cable, 3 m 1 684 465 557
UNI connecting cable, 4 core 1 684 463 539
Stylus (3x) 1 683 083 007
USB adapter 1 681 335 117
ESI[tronic] Startcenter DVD 1 987 P12 034
KTS 340 Getting Started DVD 1 687 370 308
Case 1 685 438 626
Measuring lead, red 1 684 430 065
Measuring lead, blue 1 684 430 066
Measuring lead, yellow 1 684 430 067
Ground cable, black 1 684 430 068
Test prod, red (2x) 1 684 485 035
Connection terminal, black 1 684 480 022
Important information and safety instructions 1 689 985 000
KTS 340 operating instructions 1 689 989 072
KTS 340 Quick Start Guide 1 689 989 075
EU Declaration of conformity 1 689 974 307
! Always store the KTS 340 and accessories in the
case when not in use.
3.4 Special accessories
Information on special accessories, such as vehicle-
specific connecting cables, can be obtained from your
authorized Bosch dealer.
