MicroDome Camera 200 Series Installation | en 15
Bosch Security Systems Installation Manual AR18-10-B012 | v1.55 | 2012.09
3.5 Power connection
The camera can accept power from both the DC12/24V power
input and the Ethernet input at the same time. (Changing the
power source might lead to a camera reboot.)
3.5.1 DC power connection
(Not present on NDC-274-PM version.)
Figure 3.4 DC power connection
1. Slide the plug adapter that matches your outlet socket
onto the supplied power supply.
2. Insert the power connector jack from the power supply
into the DC12/24V socket of the camera.
3. Connect the power supply to either a 230 VAC or a
120 VAC power supply outlet.
Note:
A power supply is not included in the package.
5 mm
(0.2 in)
12 VDC
24 VDC
22AWG
