IP Camera 200 Series Installation | en 25
Bosch Security Systems Installation and Operation Manual AR18-09-B003 | v1.1 | 2010.05
3.9 Resetting the camera
If the camera cannot be connected because the IP address has
changed, press and hold the reset button (7 seconds
approximately) until the LED flashes (red) to recall the factory
default values. The factory default IP address is 192.168.0.1
Figure 3.7 Reset button
3.10 Closing the unit
When the camera position is set and all adjustments have been
made, close the unit.
1. Remove the monitor cable from the jack socket.
2. Click the inner liner in position aligning the opening with
the lens.
3. If necessary clean its surface with a soft cloth.
4. Align the LED light guide of the dome with the opening at
the front of the mounting base and slot it home.
5. Use the supplied special screwdriver bit to tighten the two
tamper-resistant screws.
