SCHEMATICS
Hardware
NUMBER PART NUMBER DESCRIPTION TORQUE *
3 FP-CVR-SKIDPLT-SHTV6-V1-R1 Shuttle V6 Skid Plate
4 FP-UDH-TA-12MM-BLK-V1-R1 Universal Rear Derailleur Hanger
5 - Universal Rear Derailleur Hanger Bolt 25 Nm (18 lb·ft)
6 - Universal Rear Derailleur Hanger Washer
7 FP-LNK-UL-68MM-V1-R1 68mm Upper Link
8 FP-LNK-LL-50MM-V3-R1 50mm Out-to-Out Lower Link V3
9 FP-BRG-6902-LLUMAXECN 28mm 6902 Extended Max-E Bearing R
10 FP-BRG-6902-LLUMAX 28mm 6902 Standard Max Bearing R
11 FP-BRG-6900-LLUMAXE 22mm 6900 Ext'd Max-E Bearing R
12 FP-BLT-M8*45.7-BLK-V2 M8 Front Shock Bolt for 30.1mm Shock Spacing 13 Nm (10 lb·ft) G / L
13 FP-BLT-M14*20-BLK-V2-R2 M14x20 Link Bolt 35 Nm (27 lb·ft) L
14 FP-BLT-M10*16.5-BLK-V1 M10 Trunnion Mount Bolt 13 Nm (10 lb·ft) L
15 FP-BLT-M14*20-BLK-V3-R2 M14x20 Flip Chip Bolt 35 Nm (27 lb·ft) L
16 FP-NUT-FLIPCHIP-4.6MM-V1 4.6mm Flip Chip G
17 FP-WSH-SPC-15I*25O*3W M14x3mm Flip Chip Spacer G
18 FP-CLM-MECH-FRM-V1 Internal Routing Cable Clamp
19 FP-CVR-MECH-FRM-V2 Internal Routing Hole Cover
20 FP-CLM-DUAL-FRM-V1 Internal Routing Dual Clamp
21 FP-CLM-MECH-FRM-V2 Internal Routing Cable Clamp (Mirrored)
22 FP-CVR-MECH-FRM-V4 Internal Routing Cable Cap (Mirrored)
23 FP-SCW-FLT-M3*10-BLK CABLE PORT CLAMP SCREW BLACK
24 FP-CLM-ADEL-V1-R1 Cable Routing Adel Clamp
25 FP-SCW-BTN-M4*12-BLK-V1-R1 M4x12 Adel Clamp Mounting Bolt
26 FP-PLG-DI2-7*8*5 7x8mm Di2 Plug Ext'd
27 FP-BLT-BTN-M5*6-V1-R1 M5x6 DT Water Bottle Bolts 3 Nm (26 in·lb) L
28 PIVOT WB BOLTS V2 Top Tube Tool Bolts
29 FP-SCW-SCK-M8*18-R1-BLK M8X18 SOCKET HEAD SCREW BLACK 13 Nm (10 lb·ft) L
30 FP-WSH-8I*12O*1W-BLK M8 WASHER BLACK
31 FP-SCW-BTN-M6*14-BLK-V1-R1 M6x14 Front Bracket/Skid Plate Bolts 6 Nm (53 in·lb) L
32 FP-SCW-SCK-M6*16-BLK-V1-R1 M6x16 Rear Bracket Bolts 6 Nm (53 in·lb) L
33 FP-WSH-M6-BLK-V1-R1 M6 Washer Black
34 FP-MNT-FRNT-BATT-SLTV2-V1-R1 Front Battery Bracket
35 FP-MNT-REAR-BATT-SLTV2-V1-R1 Rear Battery Bracket
36 FP-BLT-SCK-M3*10-V1-R1 Battery Mounting Bolts 1 Nm (9 in·lb)
37 FP-BATT-PAD-60*70-V1-R1 Upper Battery Pad
38 FP-BATT-PAD-LWR-87.3MM-V1-R1 Lower Battery Pad
39 FP-PRO-SHTV6-DT-V1-R1 SHTLv6 Downtube Protector
40 FP-PRO-SHTV6-CS-V1-R1 SHTLv6 Chainstay Protector
41 FP-PRO-SHTV6-SS-V1-R1 SHTLv6 Seatstay Protector
42 FP-PRO-SHTV6-UR-V1-R1 SHTLv6 Upright Protector
43 FP-PRO-LL-50MM-V3-R1 Lower Link Protector
44 - Frame Size Sticker
Bike Care
* PRODUCT TYPE RECOMMENDED PRODUCT TORQUE *
G Grease Motorex Bike Grease 2000
L Thread Locker** Loctite Thread Locker #243 (or equivalent)
G/L Grease (Bolt Shaft) Thread Locker (Bolt Threads) See Above 25 Nm (18 lb·ft)
A Anti-Seize Motorex Copper Paste
R Retaining Compound Loctite Retaining Compound #620 (or equivalent)
**Threadlocker should always be applied to the corresponding female threads for the bolt specified
Axles
NUMBER PART NUMBER DESCRIPTION TORQUE *
101 157MM THROUGH AXLE V5 157mm UDH Rear Axle 15 Nm (11 lb·ft) G
102
