Installation and Operating Instructions
|
Power Max 2 Charging Station
579367 | REV A | 25.07.2016
5 Specications
Model EL-51866-30XX EL51866-40XX
Charging Interface SAE J1772 compliant plug
Input Rating
208-240 Vac, single-phase,
30 A max, 60 Hz
208-240 Vac, single-phase,
40 A max, 60 Hz
Wiring for Hard-wired Models L1, L2, and Ground, hard-wired with terminal block; bottom-fed
Wall Plug for Cord-connected Models NEMA 6-50P
Output Rating
208-240 Vac, single phase, 30 A max.,
60 Hz, 7.2 kW
208-240 Vac, single phase, 40 A
max., 60 Hz, 9.6 kW
Standby Power <5W
Metering Embedded non-revenue grade meter with 1% accuracy
Internal Residual Current Detection 20 mA CCID per UL 2231
Upstream Breaker
2-pole 40 A breaker on dedicated
circuit, non-GFCI type (if hard-wired)
2-pole 50 A breaker on dedi-
cated circuit, non-GFCI type
Electrical Protection
Over current, short circuit, over voltage, under voltage, ground fault,
surge protection, over temperature
Status Indicators AC present, charging, fault
Buttons/Switches Charger on/off, stop charging
Option: Network Interface WLAN
Operating Temperature -22°F to +122°F (-30°C to +50°C)
Humidity 95% related humidity, non-condensing
Charging Cable Length 18 ft (5.5 m) or 25 ft (7.6 m) straight cable
Ingress Protection Type 3R
Cooling Natural cooling
Dimension (W×H×D)
12.6×10.3×4.5 in. (320×260×115 mm), excluding charging cable, mount-
ing plate, and cable holder
Net Weight 5 lb (2 kg) excluding charging connector and cable
Certicate UL, cUL

Bosch Power Max 2 Specifications

General

Brand	Bosch
Model	Power Max 2
Category	Battery Charger
Language	English
