1 Introduction
The Power Max Level 2 Charging Station is designed for the North American market to charge plug-in electric vehi-
cles (PHEV) and battery electric vehicles (BEV). It provides AC Level 2 Charging that effectively shortens charging
time for typical electric vehicles (EVs) when compared to the Level 1 Cordset.
1.1 Applications
} Residential
} Private and public parking facilities
} Fleet
} Shopping malls and retailers
} Workplace
Please read and follow these safety warnings and operating instructions carefully before operating the Power Max
Level 2 Charging Station. Failure to follow these instructions may result in serious injury or property damage.
2 Important Safety Warnings and Instructions
IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS.
WARNING
 DisconnectelectricalpowertothePowerMaxLevel2ChargingStationbeforeinstallation.Failuretodo
so may cause physical injury or damage to the electrical system and charging unit.
CAUTION
 Toreducetheriskofre,connectonlytoacircuitprovidedwith20amperes(EL-51245-XXXXX)or40
amperes(EL-51253-XXXXX,EL-51254-XXXXX)maximumbranchcircuitovercurrentprotectionin
accordancewiththeNationalElectricalCode,ANSI/NFPA70.
} Read all the instructions before using this product.
} Children should be supervised when this product is used around children.
} Do not put ngers into the EV connector.
} Do not use this product if the EV cable is frayed, has broken insulation, or displays any other indication of
damage.
} Do not use this product if the enclosure or the EV connector is broken, cracked, open, or show any other
indication of damage.
} This product should be installed only by a qualied approved technician.
} Make sure that the materials used and the installation procedures follow local building codes and safety
standards.
} The information provided in this manual in no way exempts the user of responsibility to follow all applicable
codes or safety standards.
} Bosch and its partners are not responsible for physical injury, damage to property or equipment caused by the
installation of this product.
} This document provides instructions for the wall-mounted Power Max Level 2 Charging Station and should not be
used for any other product. Before installation or use of this product, you should review this manual carefully and
consult with a licensed contractor, licensed electrician, or trained installation expert to make sure of compliance
with local building codes and safety standards.
