ctrlX CORE
ctrlX CORE control
Bosch Rexroth AG
R911405645, Edition 03
5
2
1
3
4
Fig. 14: Device view
①
HMI and engineering port
②
Field bus master (Ethercat)
③
1 GBit/s Ethernet (configurable), not enabled for COREX-C-X2
④
Status display
⑤
Battery case
