Bosch Solution-16 safecom - Page 17

Location 671
DTMF Command Module
Options
Location 672
Expansion Board Options (V1.10)
Location 672
Expansion Board Options V1.20+)
Location 673
Telephone Line Fail Options
Location 674 - 675
Open/Close Reports For Area 2
Location 676 - 677
Open/Close Reports For Area 3
Location 678 - 679
Open/Close Reports For Area 4
Location 680 - 683
Subscriber ID Number For Area 2
Location 684 - 687
Subscriber ID Number For Area 3
Location 688 - 691
Subscriber ID Number For Area 4
Location 692 - 699
Zone Allocations For Area 1
Location 700 - 707
Zone Allocations For Area 2
0
1 = Access To Installer’s Programming Mode Allowed
2 = Installer Code Functions Allowed
4 = Disarming and Auxiliary Code Functions Allowed
8 = Master Code Functions Allowed
0
1 = Zone Expansion Board Installed
2 = Output Expansion Board Installed
4 = Momentary Keyswitch Input
8 = Latching Keyswitch Input
1 = Zone Expansion Board Installed 7 = Momentary Arm In STAY Mode 2
2 = Output Expansion Board Installed 8 = Momentary Disarm
3 = Momentary Keyswitch Input 9 = Momentary Arm Area 4
4 = Latching Keyswitch Input 10 = Momentary Disarm Area 4
5 = Momentary Arm In AWAY Mode 11 = Momentary Arm/Disarm Area 4
6 = Momentary Arm In STAY Mode 1 12 = Latching Arm/Disarm Area 4
0
0
1 = Display FAULT Indicator If Telephone Line Fails
2 = Sound Alarm When System Is Armed If Telephone Line Fails
4 = Sound Alarm When System Is Disarmed If Telephone Line Fails
Note: Option 2 & 4 Must Be Used In Conjunction With Option 1
(Eg. Program a 1, 3, 5 or 7)
Location 674 = Open Report
Location 675 = Close Report
0 0
Location 676 = Open Report
Location 677 = Close Report
0 0
Location 678 = Open Report
Location 679 = Close Report
0 0
0000
0000
0000
Location 692 = Zone 1 LED – Area 1 Codepad
Location 693 = Zone 2 LED – Area 1 Codepad
Location 694 = Zone 3 LED – Area 1 Codepad
Location 695 = Zone 4 LED – Area 1 Codepad
Location 696 = Zone 5 LED – Area 1 Codepad
Location 697 = Zone 6 LED – Area 1 Codepad
Location 698 = Zone 7 LED – Area 1 Codepad
Location 699 = Zone 8 LED – Area 1 Codepad
692 693 694 695 696 697 698 699
0 0 0 0 0 0 0 0
Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8
Location 700 = Zone 1 LED – Area 2 Codepad
Location 701 = Zone 2 LED – Area 2 Codepad
Location 702 = Zone 3 LED – Area 2 Codepad
Location 703 = Zone 4 LED – Area 2 Codepad
Location 704 = Zone 5 LED – Area 2 Codepad
Location 705 = Zone 6 LED – Area 2 Codepad
Location 706 = Zone 7 LED – Area 2 Codepad
Location 707 = Zone 8 LED – Area 2 Codepad
700 701 702 703 704 705 706 707
0 0 0 0 0 0 0 0
Z1 Z2 Z3 Z4 Z5 Z6 Z7 Z8
Solution-16/Solution-16
Safecom
Quick Reference Guide 17
Bosch Security Systems Pty Limited
