Bosch Solution 2000 Quick Reference Guide

Wiring Diagram
GND c +12V
Slow flash: Normal state
On: Trouble state
Off: Trouble state
TF008-B
18VAC@1.33A
Battery
12V 7Ah
R
B
B
G
Y
R
B
G
Y
R
B
G
Y
R
B
G
Y
3K3
PIR
Siren
Smoke detector
6K8
3K3
6K8
3K3
6K8
3K3
6K8
R
Y
G
B
_
Bosch SDI2 Bus 1,2,3 < 900mA
AUX : < 900mA
Max: 900mA
∑
I
110
0mA
<
Figure 5.1: Wiring Diagram
5.2
Control Panel Appendices | en 49
Bosch Security Systems, Inc. Quick Reference Guide 2015.06 | 03 | F.01U.298.027

Bosch Solution 2000 Specifications

General

Zones	8
Expandable Zones	Up to 16
Event Log	100 events
Partitions	2
Battery Backup	Yes
Weight	2.5kg
Backup Battery	12V 7Ah
Arming Options	Stay, Away
Communication	PSTN (optional IP module)
