Control Panel Operation with ICON LCD Codepad | en 19
Bosch Security Systems, Inc. User's Guide 2017.09 | 04 | F.01U.298.028
Zone
Indicator
Fault Description Press
Button
Zone
Indicator
Fault Condition
6 Communication Fail 6 1
2
3
4
5
6
Receiver 1 Fail
Receiver 2 Fail
Receiver 3 Fail
Receiver 4 Fail
IP Module 1 Fail
IP Module 2 Fail
7 Output and
Codepad Fail
7 1 to 2
3 to 6
Output Expanders 1 to 2 Fail
Codepads 1 to 4 Fail
8 Keyfob Low Battery 8 1 to 16 Keyfobs 1 to 16 Low Battery
Tab.5.7: Fault Indicators
See also
– Fault Indicators, page 18
5.7.1 Fault Descriptions
1 System Fault
A system fault only displays when any of the following faults occur. After entering Fault
Analysis Mode, press the [1] key to determine which of the following faults occurred.
Low Battery Fault – A low battery fault registers when the system detects a low capacity
back-up battery. The system automatically performs a battery test every four hours and every
time you arm the system.
Date and Time – The date and time fault registers every time the system is powered down.
RF Receiver Fail – This fault registers when the RF wireless receiver unit detects RF jamming,
the RF wireless receiver is disconnected from the control panel or failed, or the RF receiver’s
cover tamper switch is activated.
Output 1 to 3 Fail – This fault registers when the system detects output 1 – 3 as warning
device (Horn Speaker, Siren Running, Strobe) is disconnected or short. This fault clears once
all outputs are reconnected. Your installer must program the system for this feature to
operate.
Telephone Line Fail – A telephone line fault registers when the system detects that the
telephone line is disconnected from the control panel. Your installer must program the system
for this feature to operate.
Power Supply Fail – This fault occurs when AUX power supplies fails, +12V power fails, or
SDI2 Bus power fails. Contact your installer as soon as this fault displays.
Onboard Tamper – This fault occurs when the system detects the control panel is tampered.
RF Repeater Fail – The RF repeater 1 to 8 fault registers once the system detects that the
wireless repeater is disconnected or the repeater tamper is triggered.
2 RF Low Battery
This fault occurs when any of the RF wireless devices report a low battery condition to the
control panel. While in Fault Analysis Mode, press the [2] key until two beeps sound. This
displays the zone reporting the RF Low Battery fault.
3 Zone Tamper Fail
This fault occurs when any zone with tamper becomes an open or short circuit. Press the [3]
key until two beeps sound. This displays the zone reporting the tamper fail fault.
