2 Requirements
A prerequisite for using the keyboard is that the required hardware for an IPMatrix system is
available and configured appropriately.
Requirements for installed software
The Configuration Manager 7.60 program or later is required.
Requirements for operational purpose
Make sure the following requirements are fulfilled:
– 1 to 4ready-to-use Bosch VIDEOJET decoder with firmware 10.30 or later connected to a
surveillance network (fully installed and ready for operation)
– 1 to 4KBD-UXF or KBD-Digital keyboards (fully installed and ready for operation)
– 1 to 8 (16) displays with appropriate interface connections or adapters
Note: Up to 2 displays per decoder can be connected to VJD-8000 and VJD-7513, and up
to four displays to VJD-7523.
– Fixed or moving cameras connected to the surveillance network
– A PC with Bosch Configuration Manager program installed and connected to the
surveillance network (only for configuration purposes)
i
Notice!
Prior to operation, the IPMatrix application must be configured using the Configuration
Manager program.
IPMatrix configuration
The IPMatrix application can be configured using the Configuration Manager 7.60 program or
later.
For detailed configuration steps, refer to the IPMatrix configuration manual available on the
online product catalog.
