en Positioning and connecting
14
5 Positioning and
connecting
Positioning and connecting
Included with the appliance
Note: Check:
■ The machine for damage during
transit. Never use a damaged
machine.
■ That all accessory parts are
supplied.
If you have any complaints, contact the
dealer from whom you purchased the
appliance or our after-sales service.
Components required for installation
~ Page 22
Useful tools
■ Spirit level for aligning
■ Spanner with:
– WAF13 for undoing the transport
locks and
– WAF17 for aligning the
appliance's feet
#
+
3
( Mains cable
0 Bag:
■ Installation and operating
instructions
■ After-sales service location
directory*
■ Guarantee*
■ Cover caps for openings after
the transport locks have been
removed
■ Hose clip for securing the
water drain hose to the siphon
8 Water drain hose
@ Water supply hose on AquaStop
models
H Elbow for securing the water
drain hose
P Water supply hose on standard/
AquaSecure models
* Depends on the model
