en Positioning and connecting
24
8. Drill the holes. Use a Forstner bit for
the 35 mm hole.
9. Put the hinges in the holes and
screw them in. Screw in the counter
plates for the magnetic catches.
10.Put the hinges in the appliance
(1 + 2), push on the cover panels (3)
and screw them in place (4).
<DN>

±

 
±
PP
¡PP
¡PP
