8
Operating Instructions
Main Unit
General Parts
Outdoor Wall Mounted, Power flue Model
* The above illustration shows an example of installation.
The exact installation configuration may be slightly different.
Front Cover
Air Inlet
Water Supply Valve
Gas Supply Valve
Water Drain Valve (with Water Filter)
(Inside Water Inlet) ( p.24)
Flue Collar
Hot Water Pipe
External Weatherproof Power Point
To Next Page
