Bose 1600VI - Main Part List

35
MAIN PART LIST
Item
Number
Description Part Number Qty. Note
1 Cover, PC, Gray 182740 1
2
Chassis, 1800VI, DOM
182739 1 5, 6, 9
1800VI, ECE
199793 1 5, 7, 8
1600VI, DOM
199791 1 4, 6, 9
1600VI, ECE
199792 1 4, 7, 8
3 Screw, Sheetmetal, PHP, SERR, 6 x 1/4, blk, hs
brkt (4), cover (9), input (2), hs (4), fan brkt (4)
182721 27
4
Transformer, UI, 1800VI, 1250W, 120V
182766 1 3, 5, 6
1800VI, 1250W, IEC, 230/240V
182765 3, 5, 7, 8
1800VI, 1250W, 100V
182767 3, 5, 9
1600VI, 750W, 120V
199784 3, 4, 6
1600VI, 750W, IEC, 230/240V
199783 3, 4, 7
1600VI, 750W, 100V
199785 3, 4, 9
5
PCB Assy, Display, 1600VI/1800VI
182762 1 1, 2, 4, 5
6
PCB Assy, Input/Output, 1600VI/1800VI
182758 1 1, 2, 4, 5
7
PCB Assembly, Power Supply, 1600 VI
199782 1 1, 2, 3, 4
1800VI
182757 1, 2, 3, 5
8
PCB Assy, Regulator, 1800VI
182760 1 1, 2, 5
9 PCB Assy, Power Switch 182761 1 1, 2, 3,
4, 5
10 Line Filter, 16A/20A, 120V and 100V 182763 1 3, 6, 9
w/Tabs, 8A, 230V 182764 3, 7, 8
11 Screw, SEMS, PHP, 6-32 x 1/4, BO WAX, I/O
(4), output (4), L.F. (2)
182723 12
12 Nut, 6-32 Hex, Kep, STZ, linefilter (2), fan (2),
chassis gnd (2)
199774 8
13 Screw, SEMS, PHP, 10-32 x 3/8, BO, WAX, xfmr
(4)
182721 4
14 Washer, Int Lock, #10, STZ, binding post (4) 182730 4
15
PCB Assy, Amplifier, 1600VI
199781 1 1, 2, 4
1800VI
182756 1, 2, 5
16
PCB Assy, Output, 1600VI/1800VI
182759 1 1, 2, 4, 5
17
PCB Assy, Input, 1600VI/1800VI
182755 1 1, 2, 4, 5
18 Heatsink, Amplifier 182745 1
19 Shield, Noise, Q214, 216 182749 1
20 Screw, SEMS, PHP, 6-32 x 3/8, BO, WAX 182724 4
21 Clamp, Cable, 1.38, Nylon, caps 182732 1
22 Bracket, Heatsink 182741 1 5, 8
23 Fan, 24VDC, High Flow 182710 1
24 Post, Binding, Dual, Short, Red/Black, 120V and
100V
182711 2
24 Bind Post, Dual, Short RT Entry, 230V 182712 1 5, 7
24 Bind Post, Dual, Short LT Entry, 230V 182713 1 5, 7
25 Plug, Terminal, Blanking, Red, 230V 182714 2 7
25 Plug, Terminal, Blanking, Black, 230V 182715 2 7
26 Shield, Fan, Lower, Fab 182751 1
27 Shield, Fan, Upper, Fab 182748 1
1600VI and 1800VI Amplifiers (see Figures 13-17)
