27
Item
Number
Description Part Number Qty
Per
Assy
*See
Note
1 Cap,Cover,White 145105-1 1
Cap,Cover,Black 145105-2 1
2 Screw,Machine,8-32x.5,Pan,XREC 121316-08 1
3 Cover,Black 144590-0222 1
Cover,White 144590-0231 1
4 Knob,Control,White 148839-1 3
Knob,Control,Black 148839-2 3
5 PCB Assy.,EQ,US/International 193567-1 1 1,2
PCB Assy.,EQ,Europe 175302-3 1 1,2
PCB Assy.,Multimedia,
US/International
175302-4 1 1,2
PCB Assy.,Multimedia,Europe 175302-5 1 1,2
6 Screw,Hilo,6x.5,Pan,XREC 127015-08 3
7 Gasket,Cover-Connector 146208 1
8 Bracket,Adapter,Black 144587-2 1
9 Heatsink,7.41x5.34x2.11 144588 1
10 Screw,Tapp,8-11x1, pan, XREC/SQ 172672-16 8
11 PCB Assy.,Amplifier 149374 1 1,2
12 Tape Foam,3" 129284-030 1
13 Cable,Flat,16-pin,Terminated 144437 1
14 Clip,Spring,Transistor 144591 4
15 Screw,Shoulder,8-32x.312,Sock,Hex 143444-04 4
16 Washer,Flat,.195" 146981 4
17 Grommet,Isolator,.563" 143445 4
18 Transformer,Power,120/240V 143051 13
19 Cup,Transformer,Black 144589-2 1
20 Gasket,Transformer Cup 143514 1
AM-3P II Bass Module Part List (Figures 6 and 7)
!
Notes:
1. This part is not normally available from Customer Service. Approval from the Field Ser-
vice Manager is required before ordering.
2. The individual parts located on the PCBs are listed in the Electrical Part Lists.
3. This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
