Bose Acoustimass 3 - AM-3 P II Satellite Part List

28
Item
Number
Description Part Number Qty See
Note
1 Grille Assy,Satellite,Black 175177-1 1
Grille Assy,Satellite,Black 175177-2 1
Grille Assy,Satellite,Gray 175177-3 1
2 Twiddler,2.25" 147525 1
3 Screw,Tapp,8-11x.625, Pan,XRC/S 172672-10 4
4 Batting,Polyester,
76mmx76mmx50
144225 2
5 Enclosure,Satellite,Black 175213-1 1
Enclosure,Satellite,White 175213-2 1
Enclosure,Satellite,Gray 175213-3 1
6 Connector,Barrier Gltn,2 Pos,Blk 141405 1
7 Nameplate,Logo,Black 148056-1 1
Nameplate,Logo,Arc. White 148949-2 1
Nameplate,Logo,Gray 148949-3 1
AM-3P II Bass Module Part List (Figures 6 and 7)
AM-3P II Satellite Part List (Figure 8)
Item
Number
Description Part Number Qty
Per
Assy
See
Note
21 Woofer Assy. 5.25" 143357 1
22 Screw,Tapp,8-11x.75,pan, XRC/SQ 172672-12 4
23 Gasket,Woofer,6.5" 104794-08 1
24 Cable,Speaker 143513 1
