Bose Acoustimass 3 User Manual

39
Reference
Designator
Description Part Number Reference
R30,31 5.1Ω,5%,1/4W,
52mm,CF
121243-1215R15
R32,33,131,142,
231,242,303,313,
403,413
10.0KΩ,5%,1/8W,
1206
124895-1035
R34,138,238,308 1.00KΩ,5%,1/8W,
1206
124895-1025
R130,141,230,241,
302,312,318,402,
412,418
100KΩ,5%,1/8W,
1206
124895-1045
*R132,*143,*232,
*243,*304,*314,
*404,*414
51Ω,5%,1/4W,
Fusing
130102-510
*See Note
*R134,*145,*234,
*245,*306,*316,
*406,*416
5.1 Ω,5%,1/4W,
Fusing
130102-5R1
*See Note
R135,139,140,235,
239,240,301,307,
310,311,407,410,
411
220Ω,5%,1/8W,
1206
124895-2215
R136,236 20.0KΩ,5%,1/8W,
1206
124895-2035
R137,237,309 5.11KΩ,1%,1/8W,
1206
124894-5111
R144,244,317,417 10Ω,5%,1/8W,1206 124895-1005
R147,247 3.30KΩ,5%,1/8W,
1206
124895-3325
R146,246 0.1Ω,10%,2W,AX,
Cut
146759
R408 3.30KΩ,5%,1/10W,
0805
133626-3325
R409 20.0KΩ,5%,1/10W,
0805
133626-2035
W1,4,12,34,35,47 Jumper,Chip,0805 133627
W2,3,5-11,14-27,
29,30-33,36-42,45,
46,48,49
Jumper,Chip,1206 124896
AM-3P II Amplifier PCB Assembly Part List
!
!
*This part is critical for safety purposes. Failure to use a substitute replacement with the
same safety characteristics as the recommended replacement part might create shock, fire
and/or other hazards.
Resistors
