Reference
Designator
Description Part Number Reference
C17,125,225 10uF,20%,16V,105,
EL
137126-100
C18,120-123,126,
220-223, 226,
301-304,401-404
.0047uF,5%,50V,
X7R,1206
131754-472
*C20,*24 560uF,20%,
16V,105,EL
128548 *See Note
*C21,*25 10KuF,20%,35V,
105,EL
143623 *See Note
C22,23,26,27,124,
224,305,405
.033uF,20%,50V,
Z5U,1206
124958-3331
Reference
Designator
Description Part Number Reference
D105-107,205-207,
301,302,401,402
300mA,75V,
Switching
121501
Reference
Designator
Description Part Number Reference
Q1,102,103,110,
202,203,210,302,
303,310,402,403,
410
BPLR,N,60V,
200mA,TO-92
117921
Q101,104,109,201,
204,209,301,304,
401,404
BPLR,P,60V,
200mA,TO-92
119168
*Q105,*205,*305,
*405
BPLR,P,100V,1A,
TO-92
140349 *See Note
*Q106,*206,*306,
*406
BPLR,N,100V,1A,
TO-92
140348 *See Note
*Q107,*207,*307,
*407
BPLR,N,60V,15A,
(Formed 145319-1)
129001 *See Note
*Q108,*208,*308,
*408
BPLR,P,60V,15A,
(Formed 145319-2)
129002 *See Note
Transistors
Diodes
Capacitors
AM-3P II Amplifier PCB Assembly Part List
!
!
!
!
!
!
*See Note on Page 41.
