15
Item
Number
Part
Number
Descripton Note
1 136744 Control PCB 2
2 123802 Tweeter
3 130698 Woofer
4 126328
140711
Top Cover 4
5
5 126329 Tweeter Panel
6 126330 Woofer Panel
7 126331 Front Panel, Aluminum Plate
8 126340 Cover, Woofer
9 126332
140715
Cover, Bottom 4
5
10 126333 Chassis, Main
11 126327 Rod Antenna
12 126354 Button, Bass, Treble
13 126364 Cover, RCA Switch
14 126358
126358-1
Door, Grey
Door, White
15 126492 Spacer, Cassette Door
16 126355 Button, Volume
17 126367 Cover, AC/DC
18 126320 Radio, Rubber Sw
19 126356 Tape, Rubber Sw
20 126360 Holder, Radio Button
21 126359 Holder, Tape Button
22 126375 LCD Window
23 126376 Holder, LCD
24 126361
140721
Spacer, Power 4
5,1
25 126362 Spacer, Volume, Bass, Treble
26 126363 Holder, Control Cover
27 126387 Lever, Deck 1
28 126357 Spacer, Aux
29 126346 3 x 12mm
30 126347 4 x 20mm
31 126406 2.6 x 4mm
32 126391 2.6 x 6mm
33 126402 3 x 14mm
34 126403 3 x 12mm
35 126342 Woofer Gasket
36 126386 Front Panel Holder 1
37 126388 Spacer
38 126366
140725
Holder, Transfomer 4,1
5,1
39 126395 3 x 12 mm 1
40 126405 4 x 18 mm
41 126491 3 x 16 mm
42 126347 4 x 20 mm
43 126346 3 x 12 mm
44 126400 3 x 6 mm 1
45 126498 3 x 8 mm
47 126398 3 x 8 mm 1
48 126397 3 x 12 mm
49 126393 3 x 8 mm
50 126396 4 x 6 mm
MAIN ASSEMBLY PART LIST
Figures 8 and 9
