Bose aw-1 User Manual

19
ELECTRICAL PART LIST
Resistors
Reference
Designator
Description Part Number Note
Jumper, Misc 0 Ω 126104
R103 100k, 10%, 1/2W 126105
R104, 108, 131,
132, 135, 146, 147,
201, 205,
1k, 5%, 1/8W,
Metallic, Chip
126106 4
R206, 208, 301,
302, 329, 330, 331,
332, 553, 554, 706
1k, 5%, 1/8W,
Metallic, Chip
126106
R107, 116, 123,
127, 203, 211, 212,
519, 520, 533, 534,
539, 540, 567, 568,
574, 575, 582, 583,
588, 589, 590, 591,
614, 619, 626, 633,
634, 702
100k, 5%, 1/8W,
Metallic, Chip
126108
R109, 150, 639 6.8k, 5%, 1/8W,
Metallic, Chip
126109
R110, 112, 113,
114, 115, 312, 601,
703
2.2k, 5%, 1/8W
Metallic, Chip
126110
R111, 126, 133,
140, 218, 502, 506,
521, 522, 578, 579,
597, 599, 600, 603,
604, 605, 606, 615,
625
10k , 5%, 1/8W
Metallic, Chip
126111
R117, 118, 216 68k, 5%, 1/8W
Metallic, Chip
126112
R119, 121 12k, 5%, 1/8W
Metallic, Chip
126113
R124, 306, 314,
555, 556, 571, 572,
594
33k, 5%, 1/8W
Metallic, Chip
126114
R125, 650, 651 220k, 5%, 1/8W
Metallic, Chip
126115
R134, 462 27 Ω, 5%, 1/8W
Metallic, Chip
126116
R†135, 210, 215,
325, 326, ‡327,
‡328, †515-†518,
†545, †546, †827
27k, 5%, 1/8W
Metallic, Chip
126171 ‡4, †5
R136, 543, 544,
563, 564, 573, 618,
621, 622, 628
47k, 5%, 1/8W
Metallic, Chip
126117
R137, 138, 531,
532, 609, 612, 613,
620
22k, 5%,1/8W
Metallic, Chip
126118
R143, 204, 637 100Ω, 5%,1/8W
Metallic, Chip
126159
R144, 636 680Ω, 5%,1/8W
Metallic, Chip
126160
R145, 315, 316,
323, 324, 551, 552,
559, 560, 602
3.3k, 5%, 1/8W
Metallic, Chip
126161
R148, 607, 608,
629, 635
330 5%, 1/8W
Metallic, Chip
126162
