Bose controlcenter CC-1 User Manual

Connecting the CC-1 Zone Controller
Connect one CC-1 zone controller to FreeSpace® amplifier models IZA 190-HZ
1
, IZA 250-LZ
1
,
IZA 2120-LZ/HZ, ZA 2120-LZ/A - HZ/A, or DXA 2120, or PowerShare amplifier models PS602,
PS404A, or PS604A, or any ControlSpace® processor. Use GPI mode A- CSD. If one CC-1 is to be
used in zone 2 of the DXA 2120, then wire into VOL_2. DIP switch settings are the same.
FreeSpace
ZA 2120-LZ/HZ
Either RJ-45
on CC-1
FreeSpace
ZA 2120-LZ/HZ
FreeSpace
IZA 2120-LZ/HZ
Either RJ-45
on CC-1
Either RJ-45
On CC-1
FreeSpace
IZA 2120-LZ/HZ
FreeSpace IZA 190-HZ , IZA 250-LZ
FreeSpace IZA 2120-LZ/HZ
FreeSpace ZA 2120-LZ/A - HZ/A
FreeSpace DXA 2120
PowerShare PS602, PS404A, PS604A
ControlSpace Processor (Any)
FreeSpace and PowerShare:
609 m (2000 ft) max
ControlSpace:
152 m (500 ft) max shielded cable
30 m (100 ft) max unshielded cable
CC-1 Zone
Controller
CAT 5 cable
Use either RJ-45
connection
1
1
CC-1 Installation Guide
pro.Bose.com
12 English
Pin-to-Remote Connection Diagrams
Any ESP
RJ-45 (Main)
on CC-1
RJ-45 (Main)
on CC-1 #1
FreeSpace
DXA 2120
RJ-45 (Main)
on CC-1 #1
If one CC-1 is to be used in zone 2,
then wire into VOL_2.
DIP switch settings are the same.
1
Operates with a fixed input (B). Amp front panel A/B switch is inactive.
