Bose ControlSpace EX-1280C Service Manual

43
Reference
Designator
Description Vendor Vendor Part Number Note
R1458 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R1459 39K, 1/10W, 0603, 1% KOA RK73H1JTTD3902F
R1460 39K, 1/10W, 0603, 1% KOA RK73H1JTTD3902F
R1461 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R1463 3.3K, 1/10W, 0603, 1% KOA RK73H1JTTD3301F
R1464 3.3K, 1/10W, 0603, 1% KOA RK73H1JTTD3301F
R1465 220 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD2200F
R1466 820 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD8200F
R1467 220 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD2200F
R1468 820 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD8200F
R1469 IND82.5 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD82R5F
R1470 19.1 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD19R1F
R1471 IND82.5 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD82R5F
R1472 19.1 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD19R1F
R1473 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1500 330K, 1/10W, 0603, 1% Panasonic ERJ-3EKF3303V
R1501 100 OHM, 1/8W, 0805, 1% Yageo RC0805FR-07100RL
R1502 20K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD2002F
R1503 6.8K, 1/2W, 1210, 1% Panasonic ERJ-14NF6801U
R1504 6.8K, 1/2W, 1210, 1% Panasonic ERJ-14NF6801U
R1505 200K, 1/10W, 0603, 1% KOA RK73H1JTTD2003F
R1506 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1507 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1508 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R1509 39K, 1/10W, 0603, 1% KOA RK73H1JTTD3902F
R1510 39K, 1/10W, 0603, 1% KOA RK73H1JTTD3902F
R1511 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R1513 3.3K, 1/10W, 0603, 1% KOA RK73H1JTTD3301F
R1514 3.3K, 1/10W, 0603, 1% KOA RK73H1JTTD3301F
R1515 220 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD2200F
R1516 820 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD8200F
R1517 220 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD2200F
R1518 820 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD8200F
R1519 IND82.5 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD82R5F
R1520 19.1 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD19R1F
R1521 IND82.5 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD82R5F
R1522 19.1 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD19R1F
R1523 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1550 330K, 1/10W, 0603, 1% Panasonic ERJ-3EKF3303V
R1551 100 OHM, 1/8W, 0805, 1% Yageo RC0805FR-07100RL
R1552 20K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD2002F
R1553 6.8K, 1/2W, 1210, 1% Panasonic ERJ-14NF6801U
R1554 6.8K, 1/2W, 1210, 1% Panasonic ERJ-14NF6801U
INPUT PCB PART LIST
Resistors (continued)
