Bose ControlSpace EX-1280C Service Manual

44
Reference
Designator
Description Vendor Vendor Part Number Note
R1555 200K, 1/10W, 0603, 1% KOA RK73H1JTTD2003F
R1556 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1557 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1558 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R1559 39K, 1/10W, 0603, 1% KOA RK73H1JTTD3902F
R1560 39K, 1/10W, 0603, 1% KOA RK73H1JTTD3902F
R1561 10K, 1/10W, 0603, 1% KOA RK73H1JTTD1002F
R1563 3.3K, 1/10W, 0603, 1% KOA RK73H1JTTD3301F
R1564 3.3K, 1/10W, 0603, 1% KOA RK73H1JTTD3301F
R1565 220 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD2200F
R1566 820 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD8200F
R1567 220 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD2200F
R1568 820 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD8200F
R1569 IND82.5 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD82R5F
R1570 19.1 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD19R1F
R1571 82.5 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD82R5F
R1572 19.1 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD19R1F
R1573 0 OHM, 1A, 0603 KOA RK73Z1JTTD
R1600 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1601 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1602 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1603 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1604 11.3K, 1/10W, 0603, 1% KOA RK73H1JTTD1132F
R1605 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R1606 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R1607 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R1608 330 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD3300F
R1609 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
R1610 330 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD3300F
R1611 330 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD3300F
R1612 330 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD3300F
R1613 91 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD91R0F
R1614 91 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD91R0F
R1615 91 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD91R0F
R1616 91 OHM, 1/10W, 0603, 1% KOA RK73H1JTTD91R0F
R1617 2.7K, 1/10W, 0603, 1% KOA RK73H1JTTD2701F
R1618 2.7K, 1/10W, 0603, 1% KOA RK73H1JTTD2701F
R1650 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1651 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1652 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1653 1.91K, 1/10W, 0603, 1% KOA RK73H1JTTD1911F
R1654 11.3K, 1/10W, 0603, 1% KOA RK73H1JTTD1132F
R1655 4.99K, 1/10W, 0603, 1%, T&R KOA RK73H1JTTD4991F
INPUT PCB PART LIST
Resistors (continued)
