Bose ControlSpace SP-24 Service Manual

10
SPECIFICATIONS
Audio Performance Specifications
Frequency Response 20 Hz - 20 kHz (+0/-1 dB)
THD+N 0.003% (typical)
Channel Separation (Crosstalk) 100 dB (typical)
Dynamic Range 103 dB (typical)
Integrated DSP
Audio Latency 1.52 ms
A/D and D/A Converters 24-bit
Sample Rate 48 kHz
Audio Inputs
Inputs 2 analog, balanced, differential
Connectors, Input XLR
Input Impedance Differential 2.2 kohms @ 1 kHz
Maximum Input Level +18 dBu
Sensitivity Selectable: 0/+6/+18 dBu
Audio Outputs
Output 4 analog, balanced, differential
Connectors, Output XLR
Output Impedance Differential 200 ohms
Maximum Output Level +18 dBu
Indicators and Controls
Audio Indicators Input signal present (Green LED)
Input si
g
nal clip (Red LED)
Electrical Specifications
Mains Voltage 100 VAC - 240 VAC (+/- 10%, 50/60 Hz)
AC Power Consumption 15 W
AC Mains Connector Standard IEC (C14)
Peak Inrush Current 0.7 Amps (230 V / 50 Hz),
1.0 Am
p
s
(
120 V / 60 Hz
)
Power Dissipation 52 BTU (13.1 kcal)
Power Consumption < 15W
Physical
Rack Space Units 1 RU
Dimensions 1.8" H x 19.0" W x 8.6" D (45 mm x 483 mm x 218 mm)
Net Weight 5.9 lb (2.7 kg)
Shipping Weight 7.8 lb (3.5 kg)
Operating Temperature 32 °F - 104 °F (0 °C - 45 °C)
Storage Temperature -4 °F - 122 °F (-40 °C - 70 °C)
Humidity 95% relative humidity, maximum
General
Communication Port USB
