Bose EdgeMax EM90 Service Manual

8
Connector Diagrams
Figure 5
70V/100V
IN OUT
8 Ohm
IN OUT
70V
2.5W* 5W 10W 20W 40W 80W
8Ω
5W* 10W 20W 40W 80W NC**
100V
AUDIENCE
R
EM
O
VE
A
F
TER PRODU
C
T I
N
S
T
ALL
ATI
ON
WALL
1
0
W
2
0
W
5
W
1
0
W
5
0
W
N
C
8
Ω
2
5
W
5
W
4
0
W
8
0
W
2
0
W
4
0
W
7
0
W
1
0
0
W
I
N
P
U
T

Bose EdgeMax EM90 Specifications

General

Product color	White
Recommended usage	-
Woofer	Yes
Number of drivers	1
Speaker placement	In-wall/in-ceiling
Audio output channels	- channels
Woofer diameter (imperial)	8 \
Impedance	8 Ω
Sensitivity	96 dB
Frequency range	45 - 20000 Hz
RMS rated power	125 W
Peak Music Power Output (PMPO)	500 W
Connectivity technology	Wired
Speaker width	339 mm
Speaker height	249 mm

Weight and Dimensions

Width	390 mm
Height	13 mm
Weight	10100 g
