Bose F1 812 Service Manual

26
ELECTRICAL PART LIST
Resistors (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R183 CHIP, RES, Surge, 39 OHM, 5%, 1/4W, 1206,
WK12S, Walsin
QCF045012-3909
R184 CHIP, RES, Surge, 39 OHM, 5%, 1/4W, 1206,
WK12S, Walsin
QCF045012-3909
R185 CHIP, RES, Anti-Surge, 4.7 OHM, 5%, 1/8W,
0805,WK08S, WALSIN
QCF085021-4708
R187 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R189 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R191 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R192 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R195 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603, 1K,
OHM
QCF011030-1001
R198 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R199 CHIP, RES, 56K OHM, 1/10W, 1%, 0603 QCF011030-5602
R200 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R201 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R202 GP, CHIP, RES, 1/10W, 1%, 49.9 OHM, 0603 QCF011030-4999
R203 CHIP, RES, Anti-Surge, 680 OHM, 5%, 1/4W,
1206,WK12S, Walsin
QCF045011-6800
R205 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R301 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R302 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R303 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R304 CHIP, RES, 56K OHM, 1/10W, 1%, 0603 QCF011030-5602
R305 GP, CHIP, RES., 10K OHM, 1/8W, 1%, 0805 QCF081020-1002
R306 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R307 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R308 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R309 CHIP, RES, 56K OHM, 1/10W, 1%, 0603 QCF011030-5602
R310 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R311 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R312 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R313 GP, CHIP, RES., 39K OHM, 1/10W, 1%, 0603 QCF011030-3902
R314 GP, CHIP, RES., 2.2K OHM, 1/10W, 1%, 0603 QCF011030-2201
R316 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R317 GP, CHIP, RES., 30.1K 1/10W, 1%, 0603 QCF011030-3012
R318 GP, CHIP, RES., 1/10W, 1%, 100 OHM, 0603 QCF011030-1000
R319 GP, CHIP, RES., 39K OHM, 1/10W, 1%, 0603 QCF011030-3902
R322 GP, CHIP, RES., 39K OHM, 1/10W, 1%, 0603 QCF011030-3902
R325 GP, CHIP, RES., 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R326 CHIP, RES, 56K OHM, 1/10W, 1%, 0603 QCF011030-5602
R401 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R402 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R403 CHIP, RES, 1/4W, 1%, 1.2M OHM, , 1206 QCF041010-1204
R405 GP, CHIP, RES., 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
