Bose F1 812 Service Manual

27
ELECTRICAL PART LIST
Resistors (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R406 GP, CHIP, RES., 6.8K OHM, 1/10W, 1%, 0603 QCF011030-6801
R407 GP, CHIP, RES., 6.8K OHM, 1/10W, 1%, 0603 QCF011030-6801
R408 CHIP, RES, 2.7K OHM, 1/10W, 1%, 0603 QCF011030-2701
R409 CHIP, RES, 910 OHM, 1%, 1/10W, 0603 QCF011030-9100
R410 GP, CHIP, RES., 75K OHM, 1/10W, 1%, 0603 QCF011030-7502
R411 GP, CHIP, RES., 22K OHM, 1/10W, 1%, 0603 QCF011030-2202
R415 GP, CHIP RES, 4.02K OHM, 1/10W, 1%, 0603 QCF011030-4021
R416 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R417 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R418 GP, CHIP, RES., 75K OHM, 1/10W, 1%, 0603 QCF011030-7502
R420 GP, CHIP, RES., 1.8K OHM, 1/10W, 1%, 0603 QCF011030-1801
R421 GP, CHIP, RES., 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R422 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R423 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R426 GP, CHIP RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R427 GP, CHIP RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R428 GP, CHIP, RES., 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R430 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R432 GP, CHIP, RES., 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R435 CHIP, RES., 220 OHM, 1/4W, 1%, 1206 QCF041010-2200
R436 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R437 CHIP, RES, 4.7, OHM, 1/4, W, 1%, 1206 QCF041010-4708
R450 GP, CHIP, RES., 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R452 CHIP, RES, Anti-Surge, 4.7 OHM, 5%, 1/8W,
0805,WK08S, WALSIN
QCF085021-4708
R453 GP, CHIP, RES., 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R460 GP, CHIP, RES., 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R462 CHIP, RES, Anti-Surge, 4.7 OHM, 5%, 1/8W,
0805,WK08S, WALSIN
QCF085021-4708
R463 GP, CHIP, RES., 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R464 CHIP, RES, Anti-Surge, 4.7 OHM, 5%, 1/8W,
0805,WK08S, WALSIN
QCF085021-4708
Rx1 CHIP, RES., 470K OHM, 1/10W, 1%, 0603 QCF011030-4703
Rx2 CHIP, RES, 120K OHM, 1%, 1/10W, 0603 QCF011030-1203
Rx3 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
Rx4 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
Rx5 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
Rx6 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
Rx14 CHIP, RES, WALSIN, 4.7 OHM, 1%, 1/8W, 0805 QCF081021-4708
Rx15 CHIP, RES, WALSIN, 4.7 OHM, 1%, 1/8W, 0805 QCF081021-4708
Rx16 CHIP, RES, WALSIN, 4.7 OHM, 1%, 1/8W, 0805 QCF081021-4708
Rx17 CHIP, RES, WALSIN, 4.7 OHM, 1%, 1/8W, 0805 QCF081021-4708
Rx20 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603, 1K,
OHM
QCF011030-1001
Rx21 CHIP, RES., 470 OHM, 1/10W, 1%, 0603 QCF011030-4700
Rx25 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603, 1K,
OHM
QCF011030-1001
Rx26 CHIP, RES., 470 OHM, 1/10W, 1%, 0603 QCF011030-4700
Rx30 METAL, OXIDE, FILM, RES, 2.2K OHM, 5%, 1W,
MOF, P=12.5MM
QAO105001-2201
Rx31 METAL, OXIDE, FILM, RES, 2.2K OHM, 5%, 1W,
MOF, P=12.5MM
QAO105001-2201

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
