ELECTRICAL PART LIST
SMPS / Power Amplifier PCB Assembly
Resistors (continued)
Capacitors
Reference
Designator
Description
endor Part
Number
Note
Rx32 CHIP, RES, 240K, OHM, 1%, 1/4W, 1206 QCF041010-2403 3
Rx33 CHIP, RES, 240K, OHM, 1%, 1/4W, 1206 QCF041010-2403 3
Rx34 CHIP, RES, 240K, OHM, 1%, 1/4W, 1206 QCF041010-2403 3
Rx35 CHIP, RES, Surge, 39 OHM, 5%, 1/4W, 1206,
WK12S, Walsin
QCF045012-3909
Rx36 CHIP, RES, Surge, 39 OHM, 5%, 1/4W, 1206,
WK12S, Walsin
QCF045012-3909
Rx37 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
Rx38 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
Rx39 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
Rx40 CHIP, RES., 22 OHM, 1/4W, 1%, 1206 QCF041010-2209
Rx41 GP, CHIP, RES., 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
Rx42 GP, CHIP, RES., 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
Reference
Designator
Description
endor Part
Number
Note
C1 CAP, SAFETY, 0.47uF, 275V, 10%, X2, P=15MM PVX2394G0-4740 3
C2 CAP, SAFETY, 0.47uF, 275V, 10%, X2, P=15MM PVX2394G0-4740 3
C3 CAP, SAFETY, 0.47uF, 275V, 10%, X2, P=15MM PVX2394G0-4740 3
C4 CAP, MYLAR, P=15MM, 10%, 450V, 1uF PLM0374L0-1050
C5 CAP, ELECT, 20%, 450V, 105', CapXon, 220uF,
L.ESR, 30X36MM, PITCH=10MM
PVE0995L1-2210 3
C6 CHIP, CAP, 10%, 500V, 1210, X7R, 68nF PSL4564M0-6830
C7 CHIP, CAP, 10%, 500V, 1210, X7R, 68nF PSL4564M0-6830
C9 COND, ELECT, 1000uF, 25V, 20%, 105', 10x20mm PLE099550-1020
C10 CHIP, CAP, 10%, 500V, 1210, X7R, 68nF PSL4564M0-6830
C11 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C22 SAFETY CAP, 20%, 250V, 0.0022uF, Y1, JN,
P=10MM
PVY1395F2-2220 3
C23 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C24 SAFETY CAP, 20%, 250V, 0.0022uF, Y1, JN,
P=10MM
PVY1395F2-2220 3
C25 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C26 CAP, ELECT, 20%, 25V, 105', CapXon, 100uF,
L.ESR6.3X11MM, PITCH=2.5MMPI
PVE099551-1010
