Bose F1 812 Service Manual

29
ELECTRICAL PART LIST
Capacitors (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C28 GP, CHIP, CAP, 0.1uF, 50V, 10%,0805, TYPE X7R PYL456470-1040
C29 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C34 CAP, MPRO, 10%, 630V, 85', PPS, 33nF, P=3.5M PLR0394P0-3330
C35 CAP, ELECT, 20%, 400V, 105', CapXon, 15uF,
L.ESR10X16MM, PITCH=5MM
PVE0995K1-1560
C37 GP, CHIP, CAP, 0.1uF, 50V, 10%,1206, TYPE X7R PZL456470-1040
C38 GP, CHIP, CAP, 0.1uF, 50V, 10%,0805, TYPE X7R PYL456470-1040
C39 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C40 GP, CHIP CAP, 0.1Uf, 50V, 10%, 0805, TYPE X7R PYL456470-1040
C41 CAP, ELECT, 1000uF, 25V, 20%, 105', 10x20mm PLE099550-1020
C43 GP, CHIP, CAP, 5%, 50V, 0603, 220pF, TYPE NPO PXL410370-2210
C44 CHIP, CAP, 4.7uF, 16V, 10%, 0805, TYPE X7R PYL456440-4750
C45 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C46 CAP, ELECT, 1000uF, 25V, 20%, 105', 10x20mm PLE099550-1020
C47 CAP, ELECT, 20%, 80V, 105', CapXon, 2200uF,
L.ESR18X47MM, PITCH=7.5MMPIN
PVE099591-2220
C48 GP, CHIP, CAP, 0.1uF, 50V, 10%,1206, TYPE X7R PZL456470-1040
C49 CHIP, CAP, 4.7uF, 16V, 10%, 0805, TYPE X7R PYL456440-4750
C50 CHIP, CAP, 10%, 25V, 0805, X7R, AVX, 1uF,
2911050, 0805B105K250
PYL456450-1050
C52 CHIP, CAP, 1nF, 1000V, 10%, 1206 PZL4564Q0-1020
C53 CHIP, CAP, 0.001uF, 100V, 10%, 0805, TYPE X7R PYL4564A0-1020
C55 CAP, MYLAR, P=15MM, 10%, 450V, 1uF PLM0374L0-1050
C57 CAP, ELECT, 1000uF, 25V, 20%, 105', 10x20mm PLE099550-1020
C58 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C59 CHIP, CAP, 0.001uF, 100V, 10%, 0805, TYPE X7R PYL4564A0-1020
C60 CAP, ELECT, 1000uF, 25V, 20%, 105', 10x20mm PLE099550-1020
C61 CHIP, CAP, 10%, 50V, 0603, X7R, 560pF PXL456470-5610
C62 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C63 CHIP, CAP, 10%, 25V, 0805, X7R, AVX, 1uF,
2911050, 0805B105K250
PYL456450-1050
C64 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C65 CAP, ELECT, 20%, 80V, 105', CapXon, 2200uF,
L.ESR18X47MM, PITCH=7.5MMPIN
PVE099591-2220
C66 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C67 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C68 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C69 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C70 CHIP, CAP, 10%, 500V, 1210, X7R, 68nF PSL4564M0-6830
C71 CHIP, CAP, 5%, 250V, 1206, NPO, 100pF, 1206,
TYPE NPO
PZL4103F0-1010
C73 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C74 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C76 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C77 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C78 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C79 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C80 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C81 CAP, MYLAR, , 0.33uF, 250V, 10%, PITCH, 10MM PLM0375F0-3340
C82 CHIP, CAP, 10%, 25V, 0603, TYPE X7R, 4.7uF PXL456450-4750
C83 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C84 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
