Bose F1 812 Service Manual

30
ELECTRICAL PART LIST
Capacitors (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C85 CHIP, CAP, 5%, 250V, 1206, NPO, 100pF, 1206,
TYPE NPO
PZL4103F0-1010
C86 CAP, ELECT, 1000uF, 25V, 20%, 105', 10x20mm PLE099550-1020
C88 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C89 CAP, MYLAR, P=15MM, 10%, 450V, 1uF PLM0374L0-1050
C90 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C91 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C92 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C93 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C94 CHIP, CAP, 10%, 16V, 0603, X5R, 2.2UF PXL426440-2250
C95 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C96 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C97 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C98 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C99 CHIP, CAP, 5%, 250V, 1206, NPO, 100pF, 1206,
TYPE NPO
PZL4103F0-1010
C100 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C101 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C102 CAP, ELECT, 20%, 450V, 105', CapXon, 220uF,
L.ESR, 30X36MM, PITCH=10MM
PVE0995L1-2210 3
C103 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C104 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C105 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C107 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C108 CAP, MYLAR, , 0.33uF, 250V, 10%, PITCH, 10MM PLM0375F0-3340
C109 CHIP, CAP, 10%, 25V, 0603, TYPE X7R, 4.7uF PXL456450-4750
C110 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C111 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C112 CHIP, CAP, 5%, 250V, 1206, NPO, 100pF, 1206,
TYPE NPO
PZL4103F0-1010
C113 CHIP, CAP, 0.22uF, 50V, 10%, 0603, X7R PXL456470-2240
C114 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C115 CHIP, CAP, 10%, 500V, 1210, X7R, 68nF PSL4564M0-6830
C117 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C119 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C121 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C122 GP, CHIP, CAP, 0.1uF, 50V, 10%,0805, TYPE X7R PYL456470-1040
C123 CHIP, CAP, 10%, 500V, 1210, X7R, 68nF PSL4564M0-6830
C124 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C126 CHIP, CAP, 10%, 16V, 0603, X5R, 2.2UF PXL426440-2250
C128 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C129 COND, MYLAR, P=15MM, 10%, 450V, 1uF PLM0374L0-1050
C133 COND, ELECT, 20%, 25V, 105', CapXon, 100uF,
L.ESR6.3X11MM, PITCH=2.5MMPI
PVE099551-1010
C134 CHIP, CAP, 1uF, 25V, 10%, 0603, TYPE X7R PXL456450-1050
C136 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C138 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
