Bose F1 812 Service Manual

31
ELECTRICAL PART LIST
Capacitors (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C141 CAP, ELECT, 20%, 400V, 105', CapXon, 15uF,
L.ESR10X16MM, PITCH=5MM
PVE0995K1-1560
C142 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
C143 CHIP, CAP, 10%, 50V, 0603, X7R, 560pF PXL456470-5610
C144 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C145 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C146 CHIP, CAP, 10%, 50V, 0603, X7R, 560pF PXL456470-5610
C147 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C148 GP, CHIP, CAP, 0.1uF, 250V, 10%, 1206, X7 PZL4564F0-1040
C149 CAP, ELECT, 20%, 80V, 105', CapXon, 2200uF,
L.ESR18X47MM, PITCH=7.5MMPIN
PVE099591-2220
C150 CAP, ELECT, 20%, 80V, 105', CapXon, 2200uF,
L.ESR18X47MM, PITCH=7.5MMPIN
PVE099591-2220
C151 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C152 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C155 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C156 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C157 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C159 GP, CHIP, CAP, Walsin, 10%, 100V, 1206, 0.1uF,
TYPE X7R
PZL4564A1-1040
C160 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
C161 CHIP, CAP, 10%, 50V, 0603, X7R, 560pF PXL456470-5610
C162 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C163 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C164 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C165 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C166 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
C167 CAP.E, 47uF, 16V, 20%, 105'C, 5x11xP2 PLE099542-4700
C168 CAP.E, 47uF, 16V, 20%, 105'C, 5x11xP2 PLE099542-4700
C169 CAP, MPRO, 10%, 630V, 85', PPS, 33nF, P=3.5M PLR0394P0-3330
C171 CHIP, CAP, X2, 10%, 250V, 1808, X7R, 1nF PQL4564F0-1020
C172 CHIP, CAP, X2, 10%, 250V, 1808, X7R, 1nF PQL4564F0-1020
C174 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C195 CAP, ELECT, 20%, 80V, 105', CapXon, 2200uF,
L.ESR18X47MM, PITCH=7.5MMPIN
PVE099591-2220
C197 CAP, ELECT, 20%, 80V, 105', CapXon, 2200uF,
L.ESR18X47MM, PITCH=7.5MMPIN
PVE099591-2220
C310 CHIP, CAP, 1nF, 50V, 10%, 0603, TYPE X7R PXL456470-1020
C311 CHIP, CAP, 1nF, 50V, 10%, 0603, TYPE X7R PXL456470-1020
C312 GP, CHIP, CAP, 5%, 50V, 0603, 220pF, TYPE NPO PXL410370-2210
C313 CHIP, CAP, 0.047uF, 50V, 10%, 0603, X7R PXL456470-4730
C314 CHIP, CAP, 1uF, 25V, 10%, 0603, TYPE X7R PXL456450-1050
C315 CHIP, CAP, 1nF, 50V, 10%, 0603, TYPE X7R PXL456470-1020
C316 CHIP, CAP, 1UF, 50V, 10%, 0805, X7R PYL456470-1050
C317 GP, CHIP, CAP, 1uF, 16V, 10%, 0603, TYPE X7R PXL456440-1050
C318 CHIP, CAP, 18pF, 50V, 5%, 0603, TYPE NPO PXL410370-1800
C319 CHIP, CAP, 18pF, 50V, 5%, 0603, TYPE NPO PXL410370-1800
C420 CHIP, CAP, 4.7uF, 6.3V, 10%, 0603, TYPE X7R PXL456420-4750
