Bose F1 812 Service Manual

32
ELECTRICAL PART LIST
Capacitors (continued)
Inductors and Ferrite Beads
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C421 GP, CHIP, CAP, 0.47uF, 50V, 10%, 0603, TYPE X7R PXL456470-4740
C422 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
C426 CHIP, CAP, 4.7nF, 50V, 10%, 0603, X7R PXL456470-4720
C427 GP, CHIP, CAP, 1uF, 16V, 10%, 0603, TYPE X7R PXL456440-1050
C428 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C429 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C430 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C431 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C432 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C434 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C435 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C436 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C437 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
C439 CHIP, CAP, 10%, 500V, 1206, X7R, 150pF PZL4564M0-1510
Cx2 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
Cx4 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
Cx5 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
Cx6 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
Cx7 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
Cx8 CHIP, CAP, 47pF, 50V, 5%, 0603, NPO PXL410370-4700
Cx9 CHIP, CAP, 47pF, 50V, 5%, 0603, NPO PXL410370-4700
Cx10 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
Cx11 CHIP, CAP, 1.5nF, 50V, 10%, 0603, X7R PXL456470-1520
Cx12 CHIP, CAP, 47pF, 50V, 5%, 0603, NPO PXL410370-4700
Cx13 CHIP, CAP, 47pF, 50V, 5%, 0603, NPO PXL410370-4700
Cx17 CHIP, CAP, X2, 10%, 250V, 1808, X7R, 1nF PQL4564F0-1020
Cx18 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
Cx19 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
Cx20 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
Cx21 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
Cx23 CHIP, CAP, 10%, 16V, 0603, X5R, 2.2UF PXL426440-2250
Cx24 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
Cx26 CHIP, CAP, 10%, 16V, 0603, X5R, 2.2UF PXL426440-2250
Cx27 CHIP, CAP, 10%, 25V, 1206, X7R, 10uF PZL456450-1060
Cx28 CHIP, CAP, 0.22uF, 50V, 10%, 0603, X7R PXL456470-2240
Cx29 CHIP, CAP, 0.22uF, 50V, 10%, 0603, X7R PXL456470-2240
Cx30 CHIP, CAP, 0.22uF, 50V, 10%, 0603, X7R PXL456470-2240
Reference
Designator
Description
V
endor Part
Number
Note
FB1 CHIP, BEAD, 600, OHM, 25%, 100MHZ,, SMD, 0805,
DCR, 0.25, OHM, I>1500MA, IDC=20
SCBA08051-6010
FB2 CHIP, BEAD, 600, OHM, 25%, 100MHZ,, SMD, 0805,
DCR, 0.25, OHM, I>1500MA, IDC=20
SCBA08051-6010
FB3 CHIP, BEAD, 600, OHM, 25%, 100MHZ,, SMD, 0805,
DCR, 0.25, OHM, I>1500MA, IDC=20
SCBA08051-6010
FB4 CHIP, BEAD, 600, OHM, 25%, 100MHZ,, SMD, 0805,
DCR, 0.25, OHM, I>1500MA, IDC=20
SCBA08051-6010
L1 COMMON COIL, MIN., 4mH, AT, 1KHz, ET24-
SE6043
SILA17007-4020 3
