Bose F1 812 Service Manual

33
ELECTRICAL PART LIST
Diodes
SMPS / Power Amplifier PCB Assembly
Inductors and Ferrite Beads (continued)
Reference
Designator
Description
V
endor Part
Number
Note
L2 COMMON COIL, MIN., 4mH, AT, 1KHz, ET24-
SE6043
SILA17007-4020 3
L3 TRANSFORMER, PQ2625, SEB164, Sunshine TSSA00014-0010 3
L4 TRANSFORMER, PQ2625, SEB164, Sunshine TSSA00014-0010 3
L5 TOROID, INDUCTOR, T25*15*10, 70uH, DCR, (1-2),
75M (MAX)
SILA02016-7000
L7 INDUCTOR, 7G23B, 22UH, 10%, SAGAMI SINA03603-2200
L9 INDUCTOR, 7G23B, 22UH, 10%, SAGAMI SINA03603-2200
Reference
Designator
Description
V
endor Part
Number
Note
D1 DIP, DIODE, ITO220AB, UGF2008G-C0, 20A, 600V,
TAIWAN SEMICONDUCTOR
RHD102008-0010
D2 Diode, BRIDGE, KBJ2506 RHD202506-0010
D3 DIP, DIODE, ITO220AB, UGF2006G-C0, 20A, 400V,
TAIWAN SEMICONDUCTOR
RHD102006-0010
D4 DIP, DIODE, ITO220AB, UGF2006G-C0, 20A, 400V,
TAIWAN SEMICONDUCTOR
RHD102006-0010
D6 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D7 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D8 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D9 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D10 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D11 DIODE, CHIP, SS210, SMB, USD, MIC RCD102100-0110
D12 CHIP, DIODE, 1N4007, SMA RCD114007-0010
D13 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D14 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D15 DIODE, CHIP, SS210, SMB, USD, MIC RCD102100-0110
D16 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D17 DIP, DIODE, ITO220AB, UGF2006G-C0, 20A, 400V,
TAIWAN SEMICONDUCTOR
RHD102006-0010
D18 DIP, DIODE, ITO220AB, UGF2006G-C0, 20A, 400V,
TAIWAN SEMICONDUCTOR
RHD102006-0010
D19 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D20 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D21 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
