Bose F1 812 Service Manual

34
ELECTRICAL PART LIST
Diodes (continued)
SMPS / Power Amplifier PCB Assembly
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
D22 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D23 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D24 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D25 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D26 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D27 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D28 CHIP, DIODE, SMA, TSC, ESH1D-R3G, 15nS, 1A,
200
RCD101003-0010
D29 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D30 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D31 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D32 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D33 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D34 CHIP, DIODE, S100W, 1.0A, 100V, DO-214AC,
PANJIT
RCD100110-0010
D35 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D40 CHIP, DIODE, 1N4007, SMA RCD114007-0010
D420 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D421 GP, DIODE, BAV21WS, SOD-323, FAST,
SWITCHING TYPE
RCD100021-0010
D423 DIODE, SW, BAV99, DIODES INC,SOT-23, 3PIN,
SMT TYPE
RCD100099-0010
D461 CHIP, DIODE, US1M, SMA, 1A, 1000V, FAST, 75nS RCD100010-0030
Dx1 SCHOTTKY, DIODE, SBR0220T5-7, 0.2A, 20V RCD100220-0010
Dx2 SCHOTTKY, DIODE, SBR0220T5-7, 0.2A, 20V RCD100220-0010
Dx3 SCHOTTKY, DIODE, SBR0220T5-7, 0.2A, 20V RCD100220-0010
Dx4 SCHOTTKY, DIODE, SBR0220T5-7, 0.2A, 20V RCD100220-0010
ZD1 CHIP, ZENER, 400mW, SOD323, PDZ12B, 12V RCZ030012-0010
ZD2 CHIP, ZENER, 400mW, SOD323, PDZ12B, 12V RCZ030012-0010
ZD20 CHIP, ZENER, 400mW, SOD323, PDZ12B, 12V RCZ030012-0010
ZD21 CHIP, ZENER, 400mW, SOD323, PDZ12B, 12V RCZ030012-0010
Reference
Designator
Description
V
endor Part
Number
Note
Q1 MOSFET, N-CH, TO220AB, SiHP22N60E, 21A,
600V, VISHAY
RHM220600-1001
Q2 MOSFET, N-CH, TO220AB, SiHP22N60E, 21A,
600V, VISHAY
RHM220600-1001

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
