Bose F1 812 Service Manual

36
ELECTRICAL PART LIST
Miscellaneous
SMPS / Power Amplifier PCB Assembly
Integrated Circuits (continued)
Reference
Designator
Description
V
endor Part
Number
Note
U27 DIP, IC, REGULATOR, ST, L7805CV-DG, TO-220,
4%, 5V, 1.5A
RHI007805-0001
U28 DIP, IC, REGULATOR, ST, L7905CV-DG, TO-220,
4%, 5V, 1.5A
RHI007905-0001
U31 IC, OP, AMP, DUAL, 8P, SO-8, NJM4580, IC, OP,
AMP, DUAL, 8P
RCI004580-0001
U32 IC, OP, AMP, DUAL, 8P, SO-8, NJM4580, IC, OP,
AMP, DUAL, 8P
RCI004580-0001
U301 IC, 16P, SOP-16, UCC28063 RCI028063-0001
U401 IC, 16P, SO16N, L6599AD, ST RCI006599-0001
U402 IC, 8P, SOP-8, LM393,AUDIO, DRIVER, IR RCI000393-0001
U403 IC, LM321, SOT-23-0.95-5 RCI000321-0001
Reference
Designator
Description
V
endor Part
Number
Qty. Note
F1 FUSE, 10A, 250V, SLOW BLOW KSAA20400-0010 1 3
F1 FUSE HOLDER, 5*20MM, BXSJ-01-01 CFC021001-1001 2 3
Fx1 CHIP, FUSE, 0.5A/63V, 0468.500NR, 1206,
LITTELFUSE
KCCA01203-0001 2 3
Fx2 CHIP, FUSE, 0.5A/63V, 0468.500NR, 1206,
LITTELFUSE
KCCA01203-0001 2 3
J1 CONNECTOR, 2 PIN, P=3.96, VDE/UL, WHITE,
REMOVED PIN
CCN396031-0102 1 3
J4 CONNECTOR, 2 PIN, LEOCO, 3951, RED POST,
BASE, TOP, P=3.96
CCN396120-0102 1
J5 GP, CONNECTOR, 2, PIN, LEOCO, 3951, WHITE,
POST, BASE, TOP, P=3.96
CCN396020-0102 1
J7 GP, CONNECTOR, B3B-XH-A, 3 PIN,POST, BASE,
TOP, P=2.5
CCN250000-0103 1
J11 GP, CONNECTOR, 10 PIN, P=2.54 CCN254000-0110 1
NTC1 NTNTC, 10K OHM, 0805, NTC, RESISTOR G,
NCP18XH103F03RB
RNT003001-1690 1 3
NTC2 NTC, 10k, Ohm, 0805, NTC, RESISTOR,
NCP18XH103F03RB
RCT108050-1030 1 3
TR2 TRANSFORMER, ER49, SEB008, Sunshine TSSA00015-0010 1 3
TR3 TRANSFORMER, EEL19, SEB163, Sunshine TSSA00016-0010 1 3
TVS1 MOV 300VA 471KD20-P10R DIP BRIGHTKING RHU020471-4001 1 3

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
