Bose F1 812 Service Manual

37
ELECTRICAL PART LIST
Miscellaneous (continued)
SMPS / Power Amplifier PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Qty. Note
- AC POWER JACK, BLACK, JR-101, 50*21.9mm
(Used on subwoofer version)
CJPA11002-0010 1 3
- AMP, Gasket, EVA, 38 degree, Natural, Black,
L237.4xW11.5xT2 (Used on subwoofer version)
IVEA00727-0003 2
- AMP, Gasket, EVA, 38 degree, Natural, Black,
L237.4xW11.5xT2 (Used on subwoofer version)
IVEA00727-0004 2
- Brass Support, M3.0x0.5P, xL6 HOTA02000-0001 2
- C/W, 2P, UL1617, 18, AWG, BLUE/BROWN,
100mm, A=3.96VH, B=187#, , 3PIN (Used on
subwoofer version)
VWA310092-0001 1
- Gasket, 2, 38 degree, Natural, Blac,
L143.2xW34.6xT2 (Used on Mid/High version)
IVEA00693-0001 1
- Gasket, 3, 38 degree, Natural, Blac,
L143.2xW19xT2 (Used on Mid/High version)
IVEA00693-0002 1
- Gasket, 38 degree, Natural, Black, L216.2xW7.9xT2
(Used on Mid/High version)
IVEA00692-0001 2
- GP, TUBING, SRK, DIA=20, L=40mm, BLACK,
50%, SHRINKAGE, VINYL (Used on subwoofer
version)
DTB020000-0400 1
- GROUNDING, WIRE, UL1007, #18, YEL&GREEN,
120mm, A=OD8.0*ID4.2MM, B=STRIP, 5MM (Used
on subwoofer version)
VWP070001-0010 1 3
- HEAT SHRINKABLE TUBE, ID50xL50mm, BLACK
(Used on subwoofer version)
DTB050000-0500 1 3
- Heatsink B, AL6061, Temper-O, Nat,
L131XW120XT2.5
GALA00606-0001 1
- Heatsink D, AL6061, Temper-O, Nat,
L120XW74XT2.5
GALA00607-0001 1
- Heatsink G, AL6063, Natural, colo, L120XW50.4 GALA00608-0001 1
- Heatsink H, AL6063, Natural, colo, L80xW50.4 GALA00609-0001 1
- Heatsink I, AL6063, Natural, colo, L80XW50.4 GALA00610-0001 1
- L shape heatsink, Aluminum, 6061, L44XW24XH19 GALA00641-0001 1
- MH Amp Rear plate, AL5052, MH,
L265.25XW145.25XT3 (Used on Mid/High version)
GALA00611-0001 1
- NUT, M3.0x0.5P, NICKEL PLATED STEEL HNT009540-1230 4
- PUSH+LEVER SWITCH, RF-1003-BBC8E2L1C,
22.1*22.5*15MM (Used on subwoofer version)
MSWA09001-
0010
1
- R shape heatsink, Aluminum, 6061, L44XW24XH19 GALA00641-0002 1
- S12 Washer, OD7*ID3.2*T0.45x UNFINISHED, S HWSA17032-0045 18
- Screw, M2.6x0.45P, xL6, NICKEL, PLATE,
Steel,PAN, HEAD, TYPE, B, FREARSON
HSPA53073-1060 3
- Screw, M3.0x0.5PxL10, Zinc+CED, Coating SUS,
FLAT, HEAD, TYPE, B, HEXAGON, RECESS
HSFA53083-3100 7
- Screw, M3.0x0.5PxL15, Zinc+CED, COATING SUS,
FLAT, HEAD, TYPE, B, FREARSON (Used on
subwoofer version)
HSFA53083-3151 2
- SCREW, M3x0.5PxL8mm, NICKEL, PLATE,PAN
HEAD
HSPA43083-1080 8
- SCREW, STEEL, C1018, M3.0*0.5P*L12,
NICKEL,PAN HEAD, TYPE, B
HSPA43083-1120 16

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
