Bose F1 812 Service Manual

41
ELECTRICAL PART LIST
Resistors (continued)
F1 Model 812 Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R127 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R128 GP, CHIP, RES, 100 OHM, 1/8W, 1%, 0805 QCF081020-1000
R129 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R130 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R131 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R132 GP, CHIP, RES, 100 OHM, 1/8W, 1%, 0805 QCF081020-1000
R133 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R134 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
R135 GP, CHIP, RES, 4.99K OHM, 1/10W, 1%, 0603 QCF011030-4991
R136 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R137 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R138 GP, CHIP, RES., 75 OHM, 1/10W, 1%, 0603 QCF011030-7509
R139 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R140 GP, CHIP, RES, 1K OHM, 1%, 1/10W, 0603 QCF011030-1001
R141 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R142 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R143 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R144 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R145 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R146 GP, CHIP, RES, 10 OHM, 1%, 1/10W, 0603 QCF011030-1009
R147 GP, CHIP, RES, 1.2K, OHM, 1%, 1/10W, 0603 QCF011030-1201
R148 GP, CHIP, RES, 3.6K OHM, 1/10W, 1%, 0603 QCF011030-3601
R149 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R150 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R151 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R152 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R153 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R154 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R155 GP, CHIP, RES, 5.1K OHM, 1%, 1/10W, 0603 QCF011030-5101
R156 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R157 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R158 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R159 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R160 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R161 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R162 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R163 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R164 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R165 GP, CHIP, RES, 100K OHM, 1%, 1/10W, 0603 QCF011030-1003
R166 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R167 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R168 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R169 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R170 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R171 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R172 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R173 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R174 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R175 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R176 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401
R177 CHIP, RES, 3.9K OHM, 1/10W, 1%, 0603 QCF011030-3901
R178 GP, CHIP, RES, 2.4K OHM, 1/10W, 1%, 0603 QCF011030-2401

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
