Bose F1 812 Service Manual

42
ELECTRICAL PART LIST
Capacitors
F1 Model 812 Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
R179 GP, CHIP, RES, 3.3K OHM, 1/10W, 1%, 0603 QCF011030-3301
R180 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R181 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R182 GP, CHIP, RES, 20K OHM, 1/10W, 1%, 0603 QCF011030-2002
R183 GP, CHIP, RES, 0 OHM, 1/10W, 5%, 0603 QCF015030-0000
R184 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R185 GP, CHIP, RES, 47K OHM, 1/10W, 1%, 0603 QCF011030-4702
R186 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R187 GP, CHIP, RES, 10K OHM, 1%, 1/10W, 0603 QCF011030-1002
R188 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R189 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R190 GP, CHIP, RES, 560K OHM, 1/10W, 1%, 0603 QCF011030-5603
R191 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R192 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R193 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R194 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R195 GP, CHIP, RES, 1M OHM, 1%, 1/10W, 0603 QCF011030-1004
R198 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
R199 CHIP, RES, 330K OHM, 1/10W, 1%, 0603 QCF011030-3303
Resistors (continued)
Reference
Designator
Description
V
endor Part
Number
Note
C1 CAP, ELECT, 220uF, 16V, 20%, 105', 6.3x11mm PLE099540-2210
C2 CAP, ELECT, 470uF, 25V, 20%, 8x14mm, P=3.5mm,
D10MM, -25'C+105'C, 3.5MM
PVE099550-4710
C3 CHIP, CAP, 33pF, 50V, 5%, 0603, TYPE NPO PXL410370-3300
C4 CHIP, CAP, 15pF, 50V, 5%, 0603, NPO PXL410370-1500
C5 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C6 GP, CHIP, CAP, 100pF, 50V, 5%, 0603, TYPE NPO PXL410370-1010
C7 GP, CHIP, CAP, 100pF, 50V, 5%, 0603, TYPE NPO PXL410370-1010
C8 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C9 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C10 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C11 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C12 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C13 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C14 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C15 CHIP, CAP, 18pF, 50V, 5%, 0603, TYPE NPO PXL410370-1800
C16 CAP, ELECT, 220uF, 16V, 20%, 105', 6.3x11mm PLE099540-2210
C17 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C18 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C19 GP, CHIP, CAP, 100pF, 50V, 5%, 0603, TYPE NPO PXL410370-1010
C20 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C21 CHIP, CAP, 33pF, 50V, 5%, 0603, TYPE NPO PXL410370-3300
C22 CHIP, CAP, 33pF, 50V, 5%, 0603, TYPE NPO PXL410370-3300
C23 CAP, MINIT, ELECT, 100uF, 35V, 20%, 105', 8x7,
P=3.5, LOW ESR
PLE999560-1010

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
