Bose F1 812 Service Manual

43
ELECTRICAL PART LIST
Capacitors (continued)
F1 Model 812 Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C24 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C25 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C26 CHIP, CAP, 33pF, 50V, 5%, 0603, TYPE NPO PXL410370-3300
C27 CHIP, CAP, 18pF, 50V, 5%, 0603, TYPE NPO PXL410370-1800
C28 CAP, ELECT, 10uF, 50V, 20%, 105', 5x11mm,P=2.5, A/I PME099570-1000
C29 GP, CHIP, CAP, 470pF, 50V, 5%, 0603, NPO PXL410370-4710
C30 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C31 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C32 GP, CHIP, CAP, 100pF, 50V, 5%, 0603, TYPE NPO PXL410370-1010
C33 CHIP, CAP, 0.22uF, 50V, 10%, 0603, X7R PXL456470-2240
C34 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C35 CHIP, CAP, 33pF, 50V, 5%, 0603, TYPE NPO PXL410370-3300
C36 CHIP, CAP, 33pF, 50V, 5%, 0603, TYPE NPO PXL410370-3300
C37 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C38 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C39 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C40 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C41 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C42 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C43 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C44 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C45 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C46 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C47 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C48 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C49 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C50 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C51 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C52 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C53 CAP, ELECT, 47uF, 16V, 20%, 105'C, 5x11xP2 PLE099542-4700
C54 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C55 CAP, ELECT, 47uF, 16V, 20%, 105'C, 5x11xP2 PLE099542-4700
C56 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C57 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C58 CHIP, CAP, 1uF, 10V, 10%, 0603, TYPE X7R PXL456430-1050
C59 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C60 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C61 CHIP, CAP, 10uF, 6.3V, 10%, 0805, X7R PYL456420-1060
C62 GP, CHIP, CAP, 3.3nF, 50V, 10%, 0603, X7R PXL456470-3320
C63 GP, CHIP, CAP, 56nF, 50V, 10%, 0603, , X7R PXL456470-5630
C64 GP, CHIP, CAP, 22pF, 50V, 5%, 0603, TYPE NPO PXL410370-2200
C65 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C66 GP, CHIP, CAP, 22pF, 50V, 5%, 0603, TYPE NPO PXL410370-2200
C67 CHIP, CAP, 390pF, 50V, 10%, 0603, X7R PXL456470-3910
C68 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C69 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C70 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C71 CAP, ELECT, 20%, 25V, 100uF, Loud, L=3.5mm,105' PVE099550-1010
C72 GP, CHIP, CAP, 820pF, 50V, 5%, 0603, TYPE NPO PXL410370-8210

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
