Bose F1 812 Service Manual

45
ELECTRICAL PART LIST
Capacitors (continued)
F1 Model 812 Input-Output / DSP PCB Assembly
Reference
Designator
Description
V
endor Part
Number
Note
C117 CAP, MINIT, ELECT, 100uF, 35V, 20%, 105', 8x7,
P=3.5, LOW ESR
PLE999560-1010
C118 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C119 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C120 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C121 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C122 CHIP, CAP, 1uF, 25V, 10%, 0603, TYPE X7R PXL456450-1050
C123 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C124 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C125 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C126 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C127 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C128, CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C129 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C130 CAP, MINIT, ELECT, 100uF, 16V, 20%, 105', 5x7,
P=2mm
PLE999540-1010
C131 CHIP, CAP, 10uF, 16V, 10%, 0805, X7R PYL456440-1060
C132 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C133 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C134 CHIP, CAP, 4.7uF, 16V, 10%, 0805, TYPE X7R PYL456440-4750
C135 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C136 GP, CHIP, CAP, 820pF, 50V, 5%, 0603, TYPE NPO PXL410370-8210
C137 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C138 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C139 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C140 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C141 GP, CHIP, CAP, 820pF, 50V, 5%, 0603, TYPE NPO PXL410370-8210
C142 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C143 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C144 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C145 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C146 GP, CHIP, CAP, 820pF, 50V, 5%, 0603, TYPE NPO PXL410370-8210
C147 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C148 GP, CHIP, CAP, 680pF, 50V, 5%, 0603, NPO PXL410370-6810
C149 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C150 CHIP, CAP, 1000pF, 50V, 5%, 0603, TYPE NPO PXL410370-1020
C151 GP, CHIP, CAP, 56nF, 50V, 10%, 0603, , X7R PXL456470-5630
C152 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C153 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C154 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C155 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C156 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C157 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040
C158 GP, CHIP, CAP, 0.1uF, 50V, 10%, 0603, TYPE X7R PXL456470-1040

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
