Bose F1 812 Service Manual

46
ELECTRICAL PART LIST
F1 Model 812 Input-Output / DSP PCB Assembly
Diodes
Inductors and Ferrite Beads
Reference
Designator
Description
V
endor Part
Number
Note
B1 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
B2 GP, CHIP, RES, 0 OHM, 1/8W, 5%, 0805 QCF085020-0000
B3 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
B4 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
B5 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
B6 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
B7 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
B10 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0805,
DCR0.25 OHM, I>1500MA, IDC=20
SCBA08051-6010
L1 SMD INDUCTOR, 3.3uH, 5A, 20%, GPSR0730-3R3M,
7.2*6.6*3.0MM, GANTONG
SCNA31705-3310
L2 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L3 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L4 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L5 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L6 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L7 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L8 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L9 CHIP, BEAD, 1100 OHM, 25%, HZ0603B112R-10 SCBA06031-1120
L10 CHIP, BEAD, 1100 OHM, 25%, HZ0603B112R-10 SCBA06031-1120
L20 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
L21 CHIP, BEAD, 600 OHM, 25%, 100MHZ, SMD, 0603,
DCR0.4, OHM, I>1000MA
SCBA06031-6010
Reference
Designator
Description
V
endor Part
Number
Note
D1 SMD, Diode, SOD-323, 1SS355, 0.1A, 80V RCD113550-0010
D2 SMD, Diode, SOD-323, 1SS355, 0.1A, 80V RCD113550-0010
D3 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
D4 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
D5 SCHOTTKY, DIODE, SK32, SMC, DO-214AB RCD100032-0010
D6 SMD, LED, 2.0x1.25mm, MS-PTB2012CURSGAC,
RED/GREEN
KCD250001-0010
D7 SMD, LED, 2.0x1.25mm, MS-PTB2012CURSGAC,
RED/GREEN
KCD250001-0010

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
