Bose F1 812 Service Manual

47
ELECTRICAL PART LIST
F1 Model 812 Input-Output / DSP PCB Assembly
Diodes (continued)
Transistors
Reference
Designator
Description
V
endor Part
Number
Note
D8 SMD, LED, RED/BLUE, MS-PTB2012CURSBAC,
2.0X1.25MM
KCD260004-0010
D9 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
D10 SMD, LED, H-0805AA22E008-01, AMBER, 0805, 600-
608NM
KCD300805-0020
D12 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
D14 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
D15 DIODES, BAT54S-7-F, SOT-23 RCD100540-0010
D17 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D18 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D19 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D20 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D22 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D23 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D24 DIODE, SW, BAV99, DIODES, INC, SOT-23, 3PIN, SMT
TYPE
RCD100099-0010
D29 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
D30 GP, DIODE, SW, LL4148, TELEFUNKEN, SOD80, SMT
TYPE
RCD104148-1010
Reference
Designator
Description
V
endor Part
Number
Note
Q1 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q2 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q3 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q4 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q5 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q6 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q7 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q8 XISTR, PNP, MMBT4403, SOT-23,PNP, GENERAL
PURPOSE AMPLIFIER
RCP004403-0001
Q9 CHIP, NPN, SOT23, MMBT4401, GP, AMP, 4300310,
FAIRCHILD
RCN004401-0002
Q10 CHIP, NPN, SOT23, MMBT4401, GP, AMP, 4300310,
FAIRCHILD
RCN004401-0002

Bose F1 812 Specifications

General

Type	Powered Speaker
Power Rating	1000W
Maximum SPL	132 dB
Dimensions	664 x 334 x 372 mm
Weight	20.2 kg
LF Driver Size	12"
Enclosure Material	Composite
Inputs	2 x XLR-1/4" combo
Outputs	XLR
Mounting Options	Pole mount
HF Driver Size	8 x 2.25" high-output mid-high drivers
